GENERAL
Power source:
A C 22OV, 50160 H z
Power consumptio
8 Transistors
Semiconductor:
2 Diodes
3 Hall Ellements
Dimensions:
W i d t h ; 4 3 0 m m
H e i g h t ; 108 m m
Depth;
Weight:
2.5 kg
TURNTABLE
Type:
Semi-automatic
Motor:
DC Servo motor
Drive system:
Direct drive
Speeds:
Wow and flutter:
Rumble:
6 5 dB (DIN " B" )
Turntable:
28 cm aluminium diecast
17 cm (7" )EP Record Adaptor
2. Center Spindle
3. Turntable Sheet
4. Turntable
5. Tonearm
6. Counterbalance Weight
7. Cue Lever
8. Cartridge
9. Cut Button: CUT
12. Speed Selector Button: SPEED
SPECIFICATIONS
367 mm
NAMES OF PARTS
Type:
Static balanced straight tonearm
Effective length:
CARTRIDGE
Type:
Magnetic type
o u t p u t :
3 mV (1 kHz, 5 0 mm/set.)
Channel separation: 20 dB
2.5 g
Impedance:
47 k o h m s
Cartridge:
CART-l 37
Replacement stylus: STY-l 37
Specifications for this model are subject to change
without prior notice.
1
2
Figure 2- 1
3
4
5
6
7
