Iberital Expression Two Installations- Und Betriebshandbuch Seite 53

User MENU display: When the coff ee machine switch is in position 2 and the display in the ON position (on the
screen the name entered will be shown), press the MENU or TWO COFFEES button on the left button pad
(based on the display used) for at least 5 seconds, and enter the user level programming mode.
Technical MENU display: When the coff ee machine switch is in position 2 and the display in the OFF position (on
the screen the word OFF will be shown), press the MENU or TWO COFFEES button on the left button pad (based
on the display used) for at least 10 seconds, and enter the technical level programming mode.
IMPORTANT: Once inside the MENU, pressing on the MENU or NON-STOP button on the left button
pad (based on the display used) allows you to move through the display functions. Pressing the OK or TWO
ESPRESSOS button (based on the display used) will confi rm the chosen function and confi rm the changes.
To change between two functions, the UP or ONE ESPRESSO button moves you up an option, and the DOWN
or ONE COFFEE button (based on the display used) will drop you down an option. (See image in sections 2.9.1
and 2.9.2.)
2.9.4. User menu display
When the words SET CLOCK appear, confi rm the selection by pressing the OK button. The programming of the time
and day of the week is very important, because this information will be used by the control unit for the weekly ON/OFF
activation of the machine.
Press the UP/DOWN buttons to change the HOURS and press OK to confi rm and move on to the MINUTES and the
day of the week. After confi rming the day of the week, it will automatically go into the weekly ON/OFF programming
mode.
Pressing the UP/DOWN buttons will vary the HOURS until the desired hour is found, and then you must press the
OK button to confi rm the selection and move on to the option of MINUTES (mm), carrying out the same operation
when the word OFF appears and the rest day.
IMPORTANT: So that the machine does not come on automatically, enter (--) hyphens in the selection of HOURS
(hh.mm) for ON and OFF and the rest day.
In this section all consumption levels may be read.
Showing the number of litres of water consumed to date.
INSTALLATION AND OPERATION MANUAL
Downloaded from www.Manualslib.com
- Programming the TIME and weekly ON/OFF for the machine:
- Visualization of the counters:
Press the OK button and the display will show:
-
manuals search engine
xxxºC hh:mm
Set Clock
HH: Hours
MM: Minutes
HH.MM.xxxxxxx
xxxxxxx: Day of the week
AAA: ON
Auto On/Off
hh:
AAA:hh.mm
mm: On/off minutes
Counters
Litres
xxxxxx
IBERITAL
OFF
On/off hours
