◆ USING THE ROTATING ORIENTATION RING
Turning the crown will rotate the
rotating orientation ring.
If you point the hour hand in the
direction of the sun while keeping
the watch horizontal, the direction
between the hour hand and twelve
o'clock will face south.
(1) In the morning, with twelve
o'clock as the origin, "the
position midway between
twelve o'clock and the hour
hand counterclockwise from
twelve o'clock" will point toward
south. Refer to FIG. 1.
(2) In the afternoon, with twelve
o'clock as the origin, "the
position midway between
twelve o'clock and the hour
hand clockwise from twelve
o'clock" will point toward south.
Refer to FIG. 2.
The orientation ring is labeled with
indications for north, south, east,
and west (N, S, E, and W) as well
as numbers for degrees of angles
to allow directions to be known quickly.
* The position of the inner ring crown and details of the date indicator may
vary depending on the model.
18
Downloaded from www.Manualslib.com manuals search engine
12 o'clock
South
East
Rotating Orientation Ring
FIG. 1
12 o'clock
FIG. 2
South
