3 Inverter Manager
Interfaces
Sensor interface for
SunSpec compatible
weather stations
(optional)
Maximum cable length
for Ethernet connection
Maximum cable length
for RS485 cabling
System monitoring
Active/reactive power
setpoint
Supported baud rate for
operation of a weather
station
Power supply unit (recommended)
Type designation
Input
Output
Ambient temperature
Approvals
* Not available in all countries.
20 IMVIOBOX-IA-xx-18
RS485 (D-sub 9) /
SunSpec mode
100 m (328 ft)
1200 m (4000 ft)
Sunny Portal, SunSpec
Modbus TCP
Constant value, curve or
remotely controlled via
SunSpec Modbus
TCP with I/O Box
9600, 19200, 57600,
115200
CLCON-PWRSUPPLY*
100 Vac to 240 Vac
24 Vdc; 2.5 A
-25°C to +70°C
CE, UL
