3 Inverter Manager
3.2 Mounting the
Inverter Manager
Damage to the products and cables due to
moisture
The Inverter Manager and the I/O Box are not
protected against splash water. Consequently,
moisture can penetrate the device and damage the
products and cables.
• The Inverter Manager and the I/O Box must
be installed in a dry environment, e.g. indoors
or in a splash-proof enclosure (degree of
protection: at least IP54 (NEMA 3R)).

3.2.1 Option 1: Wall Mounting

14 IMVIOBOX-IA-xx-18
SMA Solar Technology AG
3.2.2 Option 2: Mounting on
Top-Hat Rail
Installation Manual
