No.
Spare Part name
1
Bearing sleeve
2
Ball bearing
3
Armature
4
Checking ring
5
Flat washer
6
Ball bearing
7
Stop pin
8
Spring
9
Gear box
10
Tapping screw
11
Checking ring
12
Bearing
13
Wave washer
14
Large gear
15
Tapping screw
16
Bearing cap
17
Ball bearing
18
Front cap
19
Spring washer
20
Screw
21
Clamp
22
Screw
23
Protection cover
24
Tapping screw
25
Rear cover
26
Cable clamp
27
Housing
Parts List
No.
Spare Part name
28
Column pin
29
Screw
30
Front handle
31
Small gear
32
Spring washer
33
Nut
34
Stator
35
Screw
36
Fan guard
37
Adjustable switch
38
Brush holder
39
Tapping screw
40
Carbon brush
41
Spring
42
Switch
43
Switch draw bar
44
Switch button
45
Data plate
46
Capacitor
47
Spring
48
Cable and plug
49
Cable sleeve
50
Wood-ruff key
51
Spindle
52
Lower fl ange
53
Upper fl ange
47
