2. Device Description
< Front Panel >
Video Input
Status LED
Built-in Microphone
< Rear Panel >
Power Connector
(AC24V in) (*)
Power Connector
(DC12V in)
SD/SDHC
Card Slot (*)
Reset Button
Microphone/Line In
NOTE - (*) These are optional features. Please refer to the Product List
for the full list of optional features that are available for this product.
Video Output
WPS LED (*)
Ethernet RJ45 10/100
Socket (Link/Power LED
Embedded)
Detachable Antenna (*)
WPS Button (*)
Extension I/O
Terminal Block
Audio Out
