SERVICE MANUAL
BINKS "TROPHY" SERIES
TOUCH-UP SPRAY GUNS
Binks Trophy Series Touch-up Gravity Spray
Gun is the premier spray gun for use in gravity
feed touch-up and light production spray
applications and sets a new standard in
durability, ergonomics, and atomization.
The lightweight ergonomic design offers
unsurpassed comfort and control. The latest
advanced atomization technology has been
incorporated for achieving consistent, fine
finishes when spraying a wide range of
industrial coating applications.
Binks Trophy Series Touch-up Gravity Spray
Guns are offered in two different atomization
technologies: HVLP and LVMP.
The Trophy HVLP Series of Spray
Guns can be used to operate
at high transfer efficiencies in
compliance with "California South
Coast Air Quality Management
District" regulations as a High
Volume, Low Pressure spray gun.
It is the customer's responsibility to have all operators and service personnel read and understand this manual.
77-3043-R1.3
Downloaded from
www.Manualslib.com
GRAVITY FEED HVLP & LVMP
(1466-XXXX-XXX)
II 2 G X
IMPORTANT! DO NOT DESTROY
Contact your local Binks representative for additional copies of this manual.
READ ALL INSTRUCTIONS BEFORE OPERATING THIS BINKS PRODUCT.
manuals search engine
SPECIFICATIONS
Maximum Air Pressure
Gun Body
Fluid Path
Fluid Inlet Size
Air Inlet Size
Gun Weight (less cup)
Wetted Parts (gun)
Wetted Parts (cup)
1 / 14
EN
100 psi / 6.9 bar (P-1)
Anodized Aluminum
Stainless Steel
7/16 – 14(f)
1/4" NPS / BSP(m)
12 oz. / 348 grams
Stainless Steel & PTFE
Aluminum and Plated Brass
