Specifications

System Specifications
Frequency Response
Dynamic range
THD
Crosstalk
Operating Level
Max. Input Level
CMRR
Max. Output Level
Balanced Input
Connectors
Impedance
Balanced Output
Connectors
Impedance
Key Input
Connector
Impedance
Max. Input Level
Key Output
Connector
Impedance
Max. Output Level
Expander/Gate
Trigger range
Attack
Release
Ratio
Compressor Section
Detector
Threshold
Ratio
Manual Attack Time
Manual ReleaseTime
Output gain
Enhancer
Function Switches
Gate
Release
Spectra
Key
Key Listen
Auto
I/O Meter
Stereo Link
Operating Level (Rear Panel)
Downloaded from www.Manualslib.com
Connects the External Key Input to the Balanced Output for monitoring
Sets automatic attack and release times and automated timing - program dependent
Links both channels for stereo operation. Channel 1 becomes master.
manuals search engine
<10Hz to 20kHz +0 / -0.1 dB effect out, -0.4 @ 100kHz,
<10Hz to 20kHz +0 / -0.1 dB effect in, -3dB @ >100kHz
116dBu, un-weighted, 22 Hz to 22 kHz
0.008 % typ. @ +4 dBu, 1 kHz Effect out, 0.016% effect in
Variable (Slow:100 ms / 1dB, Fast:100 ms / 100 dB)
Variable (0.3 ms / 20 dB to 300 ms / 20 dB)
Switches the detector section to external key input.
Switches the Input/Output meter to read input or output level .
Changes the internal reference level from-4 dBu to -10 dBV.
60
>95dB, 22 Hz to 22 kHz
Selectable +4dBu / -10 dBV
+21dBu, balanced
Min 40dB, >50dB @ 1kHz
+21dBu Balanced
XLR and 1/4" TRS jack
>20k Ohm balanced or unbalanced
XLR and 1/4" jack
60 Ohms balanced or unbalanced
10 k Ohm
Variable (Off to +10 dB)
<1 ms per 50 dB
Expander 1:2, Gate 1:16
-40 dB to +20 dB
Variable (1:1 to infinity:1)
Variable (0.05 to 5 Sec)
Variable (-20 to +20 dB)
Gate or Expander
Fast/slow
15dB gain reduction @ 1K
1/4" jack
+21 dBu
1/4" jack
47 Ohms
+21 dBu
RMS
off to 10
