MODULATION SOURCE
Internal:
External:
Connector:
Modulation I/O Impedance:
Output Level:
Maximum Input:
FREQUENCY MODULATION
Max Peak Deviation:
Setting Resolution:
Deviation Accuracy:
Modulation Signal:
Distortion:
PHASE MODULATION
Max Peak Deviation:
Setting Resolution:
Deviation Accuracy:
Modulation Signal:
Distortion:
AMPLITUDE MODULATION
Max Modulation Depth:
Setting Resolution:
Accuracy:
Modulation Signal:
Distortion - 150kHz – 1GHz:
4
Downloaded from www.Manualslib.com
400Hz and 1kHz sine derived from reference frequency.
Calibrated for 1Vrms sine into 600Ω
Front Panel BNC provides modulation input when external
modulation is selected and outputs internal modulation when
internal is selected.
600Ω
1Vrms EMF from 600Ω source impedance.
20V rms
800kHz, 1000MHz – 2000MHz
400kHz,
200kHz,
100kHz,
50kHz,
100kHz,
0.5kHz
<±10% ± 0.5kHz for 1kHz Internal or 1kHz, 1Vrms External
Modulation.
Internal or External 100Hz – 300kHz (± 2dB relative to 1kHz)
<2% @1kHz modulation, max. deviation (300-3.4kHz bandwidth)
80.0rads 1000MHz – 2000MHz
40.0rads
20.0rads
10.0rads
5.0rads
10.0rads
0.05rads <10.0rads deviation, 0.1rad >=10.0rads deviation
<±10% ± 0.05rads for 1kHz Internal or 1kHz, 1Vrms External
Modulation.
Internal or External 100Hz – 10kHz (± 2dB relative to 1kHz)
<2% @ 1kHz modulation, max. deviation (300-3.4kHz bandwidth)
100%, usability decreasing to 90% at 2GHz
0.5%
< ± (5% setting +1%) for 1kHz Internal or 1kHz, 1Vrms External
Modulation, <70% depth.
Internal or External 50Hz – 200kHz (±1dB relative to 1kHz)
≤3% @ 30% depth, ≤5% @ 70% depth
1GHz – 2GHz: ≤5% @ 30% depth, ≤10% @ 70% depth
@ 1kHz modulation, 300-3.4kHz measurement bandwidth.
manuals search engine
500MHz – 999.99999MHz
250MHz – 499.99999MHz
125MHz – 249.99999MHz
62.5MHz – 124.99999MHz
150kHz – 62.49999MHz
500MHz – 999.99999MHz,
250MHz – 499.99999MHz,
125MHz – 249.99999MHz,
62.5MHz – 124.99999MHz,
150kHz – 62.49999MHz
