FREQUENCY
Frequency Range:
Setting Resolution:
Accuracy/stability:
Phase Noise:
Residual FM:
REFERENCE FREQUENCY
Internal Reference Accuracy:
Internal Reference Stability:
Reference In/Out:
External Reference IN:
Internal Reference OUT:
OUTPUT LEVEL
Output Level range:
Setting Resolution:
Accuracy:
Harmonically Related Signals:
Sub-harmonically Related
Signals:
Non-harmonic Spurii:
Carrier Leakage:
Output Impedance:
Output Connector:
Reverse Power Protection:
Output Switch:
Downloaded from www.Manualslib.com
150kHz – 2000MHz
10Hz
see Reference Frequency
<–116dBc @ 25kHz offset, 500MHz Carrier.
12Hz @ 500MHz – Equivalent peak deviation in a 300Hz to 3.4kHz
bandwidth.
<± 1ppm, 15ºC – 30ºC
<± 2ppm, 5ºC – 40ºC
<1ppm/year
Rear panel BNC; can be disabled when not required for input or
output.
10MHz, 50Ω input impedance, 2 - 5Vpp
Automatic detection and selection when external reference signal is
present and Reference IN is selected on front panel.
Front panel LED indication when external is active.
10MHz, 50Ω output impedance, >2Vpp into 50Ω
Signal present when Reference OUT is selected on the front panel
–127dBm – +7dBm, all modes except AM
–127dBm – +1dBm, AM mode
0.1dB, 0.01uV –1mV
± 2dBm
<–25dBc @ +7dBm
≤1000MHz : None
>1000MHz : <–20dBc @ +7dBm
≥62.5MHz : <–60dBc
<62.5MHz : <–50dBc (150kHz – 250MHz bandwidth)
<0.5µV generated into a 50Ω load by a two turn 25mm loop 25mm
from the generator with the output set to ≤–10dBm into a sealed
50Ω load.
50Ω
Type N
50V DC, up to 25W from 50Ω source. Flashing LED indication.
RF OUT On/Off switch with LED showing ON status
