ASROCK FM2A88M Extreme4+ Schnellinstallationsanleitung Seite 3

No. Description
1
2
3
4
5
6
7
8
9
10 SATA3 Connector (SATA3_7)
11
12
13
14
15
16 SATA3 Connector (SATA3_1)
17
18
19
20 Chassis Speaker Header (SPEAKER1)
21 USB 2.0 Header (USB_5_6)
22 USB 2.0 Header (USB_7_8)
23 USB 2.0 Header (USB_9_10)
24 TPM Header (TPMS1)
25 Print Port Header (LPT1)
26 COM Port Header (COM1)
27 Infrared Module Header (IR1)
28 Front Panel Audio Header (HD_AUDIO1)
29 Chassis Intrusion Header (CI1)
30 Chassis Fan Connector (CHA_FAN1)
Downloaded from www.Manualslib.com
Power Fan Connector (PWR_FAN1)
ATX 12V Power Connector (ATX12V1)
CPU Fan Connector (CPU_FAN1)
CPU Fan Connector (CPU_FAN2)
2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
ATX Power Connector (ATXPWR1)
USB 3.0 Header (USB3_3_4)
Clear CMOS Jumper (CLRCMOS1)
SATA3 Connector (SATA3_8)
SATA3 Connector (SATA3_6)
SATA3 Connector (SATA3_5)
SATA3 Connector (SATA3_4)
SATA3 Connector (SATA3_3)
SATA3 Connector (SATA3_2)
System Panel Header (PANEL1)
Power LED Header (PLED1)
manuals search engine
FM2A88M Extreme4+
3
