DIMM Voltage
This item allows you to adjust the DIMM slot voltage.
Options: Auto, +1.8V to +2.5V in 0.1V increments. We recommend that you leave this at the default value.
Memory clock
This item sets the memory clock.
Downloaded from www.Manualslib.com
CPU Core Clock Multiplier vs. DRAM Interface Speed
CPU Ratio CPU Frequency
4 800 MHz
5 1000 MHz
6 1200 MHz
7 1400 MHz
8 1600 MHz
9 1800 MHz
10 2000 MHz
11 2200 MHz
12 2400 MHz
13 2600 MHz
14 2800 MHz
15 3000 MHz
16 3200 MHz
17 3400 MHz
* Memory Frequency = CPU Frequency / Division
manuals search engine
100 MHz 133 MHz 166 MHz
DIV Freq. DIV Freq. DIV Freq.
5 160MHz 5 160MHz 5 160MHz
5 200MHz 5 200MHz 5 200MHz
6 200MHz 5 240MHz 5 240MHz
7 200MHz 6 233MHz 5 280MHz
8 200MHz 6 266MHz 5 320MHz
9 200MHz 7 257MHz 6 300MHz
10 200MHz 8 250MHz 6 333MHz
11 200MHz 9 244MHz 7 314MHz
12 200MHz 9 266MHz 8 300MHz
13 200MHz 10 260MHz 8 325MHz
14 200MHz 11 254MHz 9 311MHz
15 200MHz 12 250MHz 9 333MHz
16 200MHz 12 266MHz 10 320MHz
17 200MHz 13 261MHz 11 309MHz
Introduction
200 MHz
DIV Freq.
5 160MHz
5 200MHz
5 240MHz
5 280MHz
5 320MHz
5 360MHz
5 400MHz
6 366MHz
6 400MHz
7 371MHz
7 400MHz
8 375MHz
8 400MHz
9 377MHz
