Checking the battery charge level

♦ To check the battery status, press the battery
charge level button
remaining charge is shown on the battery
display LED as follows:
GREEN/RED/ORANGE = maximum charge/
performance
RED/ORANGE = medium charge/performance
RED = low charge – charge the battery

Changing tools

Your cordless screwdriver has a fully automatic
spindle lock .
When the motor is at a standstill, the drive train is
locked so that you can open the drill chuck
turning it . After you have inserted the desired
tool and clamped it by turning the drill chuck
you can resume working immediately (see fig. F).
The spindle lock is released automatically when
the motor is started (by pressing the ON/OFF
switch ).

Torque selection ring/drill setting

You can set the torque using the torque pre-
selection ring (see fig. G).
♦ Select a low level for small screws or soft
materials.
♦ Select a high level for large screws, hard
materials or for removing screws.
♦ For drilling operations, select the drill setting
by moving the torque preselection ring
the position.
│ GB │ IE │ NI │ CY
■ 8
(see fig. E). The status/
by
,
to

2-speed gearbox

CAUTION!
► Operate the speed selector switch
when the appliance is at a standstill. Other-
wise the appliance could be damaged.
In first gear
(speed selector switch
you can reach a speed of approx. 400 rpm and
a high torque. This setting is suitable for all screw-
driving jobs.
In second gear
(speed selector switch
you can reach a speed of approx. 1400 rpm for
carrying out drilling work.

Changing the cutter knife blade

WARNING!
■ Wear protective gloves!
♦ Press the red button on the rear end of the
cutter knife to pull out the spare blade holder
completely.
♦ Carefully remove the worn upper blade.
♦ Slide the spare blade holder back into the
housing.
Detaching the blunt cutter
knife blade
♦ Break the blunt section of the blade off at the
defined breaking point using a pair of pliers.
only
in position 1)
in position 2)
