Converting the type of gas

Replacing the injectors

A
B
D
If the appliance is not presetted for the available type
of gas, it must be converted.
The conversion to a different type of gas should be
carried out by a licensed expert, too.
The gas type and pressure that have been preset in
the factory are indicated on the identification plate on
the right external side of the pan drawer.
For converting the appliance to an other type of gas
its injectors, sometime its bypasses as well must be
replaced. The minimum flow must be regulated.
To replace the injectors, proceed as follows:
• Disconnect the hob from the mains.
• Remove the pan supports.
• Remove the burner cap (A) and burner (B) from
the hob (C).
C
• Take out the injector (D) and replace it with one
suitable for the new type of gas (see section
"General injectors table").
• Replace the gas label with the new one provided
with the injectors kit.
• Place the burner (B) on the hob (C).
• Lay the burner cap (A) accurately on the
burner (B).
• Place the pan supports lengthways over the hob
on the step at the edge of the hob.
In the event that the appliance has to be converted to
LPG 30/50 mbar the bypass of the taps must be
substituted.
