Parameter-Liste - Motrona Fm210 Bedienungsanleitung

Parameter-Liste

Nr. Parameter
000 Factor 1
001 Factor 2
002 Reserved
003 Ref. Speed High
004 Ref. Speed Low
005 Ref. Ramp
006 Jog Speed
007 Jog Ramp
008 Trim Speed
009 Offset
010 Special Mode
011 Reserved
012 Reserved
013 Encoder Mode
014 Z Pulse
015 Sampling Time
016 Overshoot
017 Calculation Freq
018 Direction
019 Correction Basis
020 Correction Freq
021 Correction Value
022 Test
023 Reserved
024 Reserved
025 Input 1 Config
026 Input 1 Function
027 Input 2 Config
028 Input 2 Function
029 Input 3 Config
030 Input 3 Function
031 Input 4 Config
032 Input 4 Function
033 Output 1 Config
034 Output 2 Config
035 Output Polarity
036 Diff Error
037 Reserved
