●Adjusting Position and Focus ●
(Setting up for the first time or after moving)
■ Raising the Projection Position (Adjusting the front foot)
When moving the projector, make sure
the front foot is retracted.
Correcting Keystone Distortion
You can adjust the vertical tilt to a maximum of
about 30°*(20° when projecting a component
video image with a ratio of 16:9).
Wide Top
* The greater the angle of tilt, the harder the
image is to focus. Setup the projector at a lower
angle of tilt.
■ Adjusting Focus
A f t e r k e y s t o n e c o r re c t i o n a n d
sharpness adjustments, the image
may be unfocused.
If keystone correction or zoom adjustments are performed, the "Image Shift" adjustment screen is
displayed.
● Turning the Projector off ●
Turn off all connected equipment.
Press
control or control panel.
Downloaded from www.Manualslib.com
Normal Wide Base
User's Guide "Adjusting the Projection Position (Image Shift)"
twice on the remote
manuals search engine
Foot Adjust
Lever
You can adjust the front foot to raise the
projection angle up to a maximum of 10°.
• You can also make keystone
corrections from the configuration
menu.
User's Guide "Settings Menu"
• Hold down
and press
t h a n o n e s e c o n d t o r e s e t t h e
correction value to the default
setting.
• Adjust the horizontal tilt by turning
the left rear foot.
Rear Adjustable
Foot
Extend
■ Adjusting Projection Size
Enlarge
After the confirmation buzzer beeps
twice, unplug the power cable.
Electricity is consumed if only the projector's
power is turned off.
Attach the lens cover.
for more
Retract
Reduce
