I/O Panel
<20mm
* Please use a 19V power adaptor for the DC jack. This jack accepts dual barrel
plugs with an inner diameter of 2.5 mm and an outer diameter of 5.5 mm, where
the inner contact is +8 (±10%) through +19 (±10%) VDC and the shell is GND. The
maximum current rating depends on the power adaptor. The following are examples
of power adaptors that may be used:
DELTA
HP
FSP
** There are two LEDs on the LAN port. Please refer to the table below for the LAN
4
Downloaded from
www.Manualslib.com
1
2
1*
DC Jack
2
USB 3.0 Ports (USB01)
3
DVI-I (DVI1)
4
eSATA Connector (eSATA1)
5**
LAN RJ-45 Port
6
USB 2.0 Ports (USB23)
7
Front Speaker (Lime)
8
Microphone (Pink)
9
HDMI Port (HDMI1)
DELTA-ADP-150TB-150W/19V
HP-TBC-BA52-150W/19V
FSP-FSP150-ABAN1-150W/19V
port LED indications.
LAN Port LED Indications
Activity/Link LED
Status
Description
Off
No Link
Blinking Data Activity
On
100Mbps connection Green
manuals search engine
3
4
9
SPEED LED
Status
Description
Off
10Mbps connection
Orange 100Mbps connection
1Gbps connection
ASRock H61TM-ITX Motherboard
5
6
8
7
ACT/LINK
SPEED
LED
LED
LAN Port
