Intel H61 Chipset
SATA2 Connector (SATA_1)
USB 2.0 Header (USB8)
Chassis Fan Connector (CHA_FAN1)
Consumer Infrared Module Header (CIR1)
SATA2 Connector (SATA_0)
USB 2.0 Header (USB6_7)
Mini PCI Express Slot (MINI_PCIE1)
USB 3.0 Header (USB3_0_1)
SATA Power Connector (SATA_POW1)
Power LED Header (PLED1)
System Panel Header (PANEL1)
Backlight Power Jumper (BKT_PWR1)
Panel Power Jumper (PNL_PWR1)
LVDS Connector (LVDS1)
2 x 204-pin DDR3 SO-DIMM Slots (DDR3_A1, DDR3_B1)
Backlight & Amp Volume Control Header (BLT_VOL1)
COM Port Header (COM1)
1155-Pin CPU Socket
USB 2.0 Header (USB4_5)
SPI Flash Memory (32Mb)
CPU Fan Connector (CPU_FAN1)
PCI Express 3.0 x4 Slot (PCIE1)
Digital MIC Header (DMIC1)
HDMI_SPDIF Header (HDMI_SPDIF1)
Front Panel Audio Header (HD_AUDIO1)
Analog Surround Audio Header (HD_AUDIO2)
3W Audio AMP Output Wafer Header (SPEAKER1)
Home Theater PC Header (HTPC1)
LPC Debug Header (LPC1)
Clear CMOS Jumper (CLRCMOS1)
ASRock H61TM-ITX Motherboard
