Inhaltszusammenfassung für Märklin 60883

  • Seite 1 Rückmeldemodul L88 60883...
  • Seite 2: Inhaltsverzeichnis

    Inhaltsverzeichnis: Sommaire : Seite Page Bestimmungsgemäße Verwendung Utilisation conforme à sa destination Sicherheitshinweise Remarques importantes sur la sécurité Wichtige Hinweise Information importante Ein- und Ausgänge des Link 88 Entrées et sorties du Link 88 Anschluss Connectez Anschluss Übersicht Vue d’ensemble des branchements Konfiguration des L88 Configuration du L88 Utilisation comme matrice de touches...
  • Seite 3 Indice de contenido: Innehållsförteckning: Página Sidan Uso correcto Användning av produkten Instrucciones de seguridad Säkerhetsanvisningar Notas importantes Viktig information Entradas y salidas del Link 88 In- och utgångar på Link 88 Anslutning Montaje Esquema sinóptico de conexionado Översikt: Anslutninga Configuración del L88 Konfiguration av L88 Uso como matriz de teclas Användning som knapp-matris...
  • Seite 4: Bestimmungsgemäße Verwendung

    Ein- und Ausgänge des Link 88 Bestimmungsgemäße Verwendung Stromversorgung: Schaltnetzteil 66361 oder 66201. • Das Rückmeldemodul L88 ist für den Anschluss an die Central Stationen (CS2) 60213/60214/60215 ab der Soft- Anschluss an Central Station / Terminal ware Version 3.8.xx und höher bestimmt. Masserückführung (bei Verwendung als Rückmelder) •...
  • Seite 5: Anschluss

    Anschluss Anschluss an die Central Station Den Link 88 direkt an den Boosteranschluß der CS2 oder an das Terminal 60125 anschließen, danach die Stromversorgung 66361 oder 66201 einstecken. Bus 1 Bus 3 Bus 2 Central Station / Terminal S88 Link 9 10 11 12 13 14 15 16...
  • Seite 6: Anschluss Übersicht

    Anschluss Übersicht Ein bestehender Anschluss des S88 an der Central Station 2 kann beibehalten werden An einen Link 88 können maximal 31 S88 und/oder 62 S88AC/S88DC angeschlossen werden. 8 7 6 5 4 3 2 1 decoder s 88 9 10 11 12 13 14 15 16 Max.
  • Seite 7 Stromversorgung: 5V im Mischbetrieb von Märklin S88 und S88 AC/DC (wie in Abb. dargestellt), sowie Produkten anderer Anbieter. 12V nur in Verbindung S88 AC/DC. Bei einer Stromversorgung mit 12V wird die Störanfälligkeit verringert. PIN Belegung Pin RJ45 Farbe Pin S88 Name Beschreibung Pin RJ45 EIA/TIA 568A...
  • Seite 8: Konfiguration Des L88

    Konfi guration des L88 jetzt können die einzelnen Daten eingestellt werden. Vor Inbetriebnahme des L88 muss dieser erst konfi guriert werden. Dazu gehen Sie in der CS auf setup/Info, nun mit Dazu gehen Sie in der CS auf setup/Info, nun mit dem Symbol Werkzeug in den Konfi gurationsmodus.
  • Seite 9: Verwendung Im Memory (Beispiel): Gehen Sie In Konfigurationsmodus

    Adressierung der Module: z.B. Kontakt 8 Modul 2 Die Module adressieren sich durch das Einstecken automa- Bus 2 tisch. Für die Einstellungen in der Central Station finden Sie nachfolgend die Adresssen. Kontakte (Gleis): 1-16 Tasteradressen: 101-164 Bus 1: 1001 -1496 (z.B. 1005 = 1. Modul, Kontakt 5) Bus 2: 2001 - 2496 1.2 Verwendung im Layuot (Beispiel): Bus 3: 3001 - 3496...
  • Seite 10 Beispiele für den Anschluss der verschiedenen Melde-Kontakte Masserückführung für alle Gleis-Kontakte nur 1x erforderlich. Anschluss an das Märklin H0-Gleissystem mit dem Schaltgeis Bus 1 Bus 3 Bus 2 = Meldende Fahrt- richtung S 88 Link Fahrtrichtungsabhängige 9 10 11 12 13 14 15 16 Meldung.
  • Seite 11 Anschluss an das Märklin H0-Gleissystem mit Reedkontakt. Fahrtrichtungsunabhängige Bus 1 Bus 3 Bus 2 Meldung S 88 Link 9 10 11 12 13 14 15 16 Masserückführung ist pro Reed-Kontakt erforderlich Anschluss an Zweileiter-Gleis- systeme, unabhängig von der Bus 1 Bus 3 Bus 2 Spurgröße nur mit Reedkontakt.
  • Seite 12: Nutzung Als Tasten-Matrix

    Nutzung als Tasten-Matrix (Stellpult): Anschluss Stellpult Wollen Sie den L88 für eine Tasten-Matrix verwenden, dann Es können max. 8 Stellpulte (Eingang 9 - 16) angeschlossen müssen folgende Einstellung vorgenommen werden. werden. 72720 / 72729 / 7272 Eingang Durch die Einstellung Matrix können max. 64 Taster (32 Ma- gnetartikel oder 64 Fahrstraßen) unterstützt werden.
  • Seite 13 Danach das zugeordnete Gerät (hier 17) eintragen. Adresstabelle für die Tasten Bitte beachten, die Diode muss in Sperrrichtung zum Ausgang eingebaut sein. Beispiel Taster 1: Ausgang 9 angeschlossen an Eingang 1 erhält die Adresse 101. (Eingang) Ist alles richtig eingetragen, bestätigen Sie es mit dem grünen Haken.
  • Seite 14: Using The Product As Intended

    • The L88 feedback module is designed for connection Current supply: 66361/66365 or 66201 switched mode power pack. to the L88 (60883) and the 60213/60214/60215 Central Connections to the Central Station / Terminal Stations (CS2) with Software Version 3.8.xx and higher.
  • Seite 15: Connect

    Connect Connections to the Central Station Connect the Link 88 directly to the Booster connection on the CS2 or to the 60125 Terminal. After that plug in the 66361/66365 or 66201 power supply. Bus 1 Bus 3 Bus 2 Central Station / Terminal S88 Link 9 10 11...
  • Seite 16: Overview Of Connections

    Overview of Connections An existing connection from the S88 to the Central Station 2 can be kept. A maximum of 31 S88 units and/or 62 S88AC/S88DC units can be connected to a Link 88. 8 7 6 5 4 3 2 1 decoder s 88 9 10 11 12 13 14 15 16 Maximum...
  • Seite 17 Current Supply: 5volts in mixed operation of S88 and S88 AC/DC Märklin products (as shown in the illustration), as well as products of other makes. 12 volts only in conjunction with the S88 AC/DC. The susceptibility to interruptions is reduced with a 12 volt power supply. PIN Assignment for the RJ45 Plug Color S88 Pin Name...
  • Seite 18: Configuration For The L88

    Confi guration for the L88 Now the individual data can be set.. The L88 must fi rst be confi gured before using it for the fi rst time. To do this go into the CS to setup/Info and with the tool To do this go into the CS to setup/Info and with the tool symbol go into the confi guration mode.
  • Seite 19: Use In The Memory (Example) Go Into The Configuration Mode

    Addresses for the Module: e.g. Contact 8 Modul 2 The module automatically get an address when it is plugged Bus 2 in. You will find below the addresses for settings in the Central Station. Contacts (track): 1-16 Button controller addresses: 101-164 Bus 1: 1001 -1496 (ex.
  • Seite 20 Sample Connections for the Different Feedback Contacts Only one ground return is required for all track contacts. Connections to the Märklin H0 track system with the Circuit Track Bus 1 Bus 3 Bus 2 = Direction of tra- vel feeding back S 88 Link Feedback is dependent on 9 10 11...
  • Seite 21 Connections to the Märklin H0 track system with Reed Switches Feedback is independent of the direction of travel Bus 1 Bus 3 Bus 2 S 88 Link 15 16 9 10 11 12 13 14 Ground return is required per reed switch Connections to two-rail track sys- tems, independent of the gauge only with Reed Switches.
  • Seite 22: Use As A Button Matrix

    Use as a Button Matrix (Control Box): Connections for a Control Box If you want to use the L88 for a button matrix, then the A maximum of 8 control boxes (Inputs 9 - 16) can be con- nected. following setting must be done. 72720 / 72729 / 7272 Input A maximum of 64 button controllers (32 solenoid devices or...
  • Seite 23 After that enter the assigned device (here 17). Address Table for the Buttons Please note, the diode must be installed in the blocking direction at the output. Example Button 1: 9 output connected to input 1 is replaced by the address. 101. (Input) 1 (Output) If everything has been entered correctly, confirm it with the...
  • Seite 24: Utilisation Conforme À Sa Destination

    Entrées et sorties du Link 88 Utilisation conforme à sa destination Alimentation électrique : Alimentation de coupure 66361 ou • Le module de rétrosignalisation L88 DC est conçu pour être branché aux Central Stations (CS2) 60213/60214/60215 à 66201. partir de la version logicielle 3.8.xx et plus. Branchement à...
  • Seite 25: Connectez

    Connectez Branchement à la Central Station Branchez le Link 88 directement sur la prise booster du CS2 ou au terminal 60125, puis branchez la prise électrique 66361 ou 66201. Bus 1 Bus 3 Bus 2 Central Station / Terminal S88 Link 9 10 11 12 13 14 15 16...
  • Seite 26: Vue D'ensemble Des Branchements

    Vue d’ensemble des branchements Une connexion existante du S 88 à la Central Station 2 peut être conservée. Vous pouvez brancher au maximum 31 S88 et/ou 62 S88AC/S88DC au Link 88. 8 7 6 5 4 3 2 1 decoder s 88 9 10 11 12 13 14 15 16 Max.
  • Seite 27 Alimentation en courant : 5V en exploitation mixte de produits Märklin S88 et S88 CA/CC (comme représenté), ainsi que de produits d’autres fournisseurs. 12V uniquement en liaison avec S88 CA/CC. Une alimentation en courant de 12 V permet de réduire la sensibilité aux interférences. Affectation PIN du connecteur RJ45 Couleur PIN S88 Nom...
  • Seite 28: Configuration Du L88

    Confi guration du L88 Agrandissez la fenêtre Info Vous devez confi gurer le L88 avant la mise en service. Pour cela, allez dans le CS sur setup/Info, puis appuyez sur cela, allez dans le CS sur setup/Info, puis appuyez sur l’icône outil pour ouvrir le mode confi guration.
  • Seite 29 (configuration d’usine 67 ms). Par exemple : Kontakt 8 Modul 2 • Colonnes Clavier Bus 2 Saisie des colonnes (max. 8) du clavier Matrice • Lignes clavier Saisie des lignes (max. 8) du clavier Matrice Adressage des modules : Les modules s’adressent automatiquement dès le bran- chement.
  • Seite 30 Exemples pour le raccordement des différents contacts de (rétro) signalisation Retour à la masse nécessaire seulement une fois pour tous les contacts de voie . Raccordement au système de voie Märklin H0 avec la voie de commutation Bus 1 Bus 3 Bus 2 = sens de marche à...
  • Seite 31 Raccordement au système de voie Märklin H0 avec contact à lames souples Bus 1 Bus 3 Bus 2 Signal en fonction du sens de marche S 88 Link 9 10 11 12 13 14 15 16 Retour à la masse nécessaire pour chaque contact à lames souples Raccordement à...
  • Seite 32: Utilisation Comme Matrice De Touches

    Utilisation comme matrice de touches (pupitre d’aiguillage) : Branchement pupitre d’aiguillage Vous pouvez brancher jusqu’à 8 pupitres d’aiguillage Pour utiliser le L88 pour une matrice de touches, vous devez (entrées 9-16) configurer les paramètres comme suit : 72720 / 72729 / 7272 Entrée La configuration Matrix permet de prendre en charge jusqu’à...
  • Seite 33 Puis saisissez l’appareil affecté (ici 17). Tableau d’adresses pour les touches Attention : la diode doit être montée sens non passant vers la sortie. Exemple touche 1 : 9 sortie connectée à l‘entrée 1 = adresse 101. (Entrée) Vérifiez les saisies puis confirmez avec le crochet vert. Con- 1 (Sortie) firmez l’écran qui s’affiche en appuyant sur le flèche bleue.
  • Seite 34: Beoogd Gebruik

    In- en uitgangen van de Link 88 Beoogd gebruik Voeding: netadapter 66361 of 66201. • De terugmeldmodule L88 is bestemd voor het aansluiten op het Central Station (CS2) 60123/60214/60125 met een Aansluiting op Central Station / Terminal softwareversie vanaf 3.8.xx en hoger. T Massa-retourleiding (bij het gebruik als terugmelder) •...
  • Seite 35: Aansluiten

    Aansluiten Aansluiten op het Central Station De Link 88 direct op de boosteraansluiting van het CS2 of op de Terminal 60125 aansluiten, daarna de stekker van de stroomvoorziening 66361 of 66201 er in steken. Bus 1 Bus 3 Bus 2 Central Station / Terminal S88 Link...
  • Seite 36: Aansluit Overzicht

    Aansluit overzicht Een bestaande aansluiting van de S88 op het Central Station 2 kan gehandhaafd blijven. Op de Link 88 kunnen maximaal 31 S88 en/of 62 S88AC/S88DC aangesloten worden.. 8 7 6 5 4 3 2 1 decoder s 88 9 10 11 12 13 14 15 16 Max.
  • Seite 37 Stroomvoorziening: 5V in gemengd bedrijf van Märklin producten S88 en S88 AC/DC (zoals in afb. weergegeven), alsmede producten van andere aanbieders. 12V alleen in combinatie met S88 AC/DC. Bij een stroomvoorziening met 12 V wordt de invloed van stoorsignalen verminderd. PIN bezetting van de RJ45 stekker Kleur Stift S88 Naam...
  • Seite 38: Configuratie Van De L88

    Confi guratie van de L88 nu kunnen verschillende gegevens ingesteld worden. Voor het in gebruik nemen van de L88 moet deze eerst geconfi gureerd worden. Daarvoor gaat u in het CS naar Daarvoor gaat u in het CS naar setup/info, nu met het sleuteltje naar de confi guratiemo- dus.
  • Seite 39 Adressering van de module: Voorbeeld: Meldcontact 8 Modul 2 De module adresseert zich automatisch bij het insteken. Bus 2 Voor de instelling in het Central Station vindt u onderstaand de adressen. Contact (spoor): 1 - 16 Drukknop adressen 101-164 Bus 1: 1001 -1496 (bijv. 1005 = 1ste module, contact 5) Bus 2: 2001 - 2496 1.2 Gebruiken in het layout (voorbeeld) ga naar de confi- Bus 3: 3001 - 3496...
  • Seite 40 Voorbeelden voor het aansluiten van de verschillende meldcontacten Massa retour voor alle railcontacten slechts 1x nodig. Aansluiting aan het Märklin H0-railsysteem met een schakelrail Bus 1 Bus 3 Bus 2 = Meldende rijrich- ting S 88 Link Rijrichtingafhankelijke 9 10 11 12 13 14 15 16 melding...
  • Seite 41 Aansluiting aan het Märklin H0- railsysteem met een reedcontact Bus 1 Bus 3 Bus 2 Rijrichtingonafhankelijke melding S 88 Link 9 10 11 12 13 14 15 16 Massa retour is voor elk reedcontact nodig Aansluiting aan het twee- Bus 1 Bus 3 Bus 2 railsysteem, onafhankelijk van...
  • Seite 42: Benutten Als Drukknoppen-Matrix

    Benutten als drukknoppen-matrix (schakelpaneel): Aansluiten schakelkastjes Wilt u de L88 gebruiken voor een drukknoppen-matrix, dan Er kunnen max. 8 schakelkastjes (ingang 9-16) aangesloten worden. moeten de volgende instellingen uitgevoerd worden. 72720 / 72729 / 7272 Ingang Door de instelling matrix kunnen max. 64 drukknoppen (32 De instellingen worden in de configuratiemodus van het magneetartikelen of 64 rijwegen) ondersteunt worden.
  • Seite 43 daarna het toegewezen apparaat (hier 17) invoeren. Adrestabellen voor de toetsen Let er op, de diode moet in sperrichting naar de uitgang zijn ingebouwd. Voorbeeld Knop 1: 9 uitgang aangesloten op ingang 1 = adres 101. (Ingang) Is alles juist ingevoerd, bevestig dat met het groene vinkje. 1 (Uitgang) Met de nu in het beeld verschijnende toets met de blauwe pijl tussendoor opslaan.
  • Seite 44: Notas Importantes

    Notas importantes Uso correcto • Las instrucciones de empleo forman parte íntegra del • El módulo de señalización de respuesta L88 se ha producto y, por este motivo, deben conservarse y entre- previsto para su conexión a las Central Stations (CS2) garse al nuevo usuario, si se transmite el producto a otra 60213/60214/60215 a partir de la versión de software 3.8xx y más recientes..
  • Seite 45: Montaje

    60881/60882 Interruptor de alimen- 60880/6088 tación eléctrica S88/ 60881/60882 S88AC/S88DC Alimentación eléc- Bus 1 Bus 3 Bus 2 trica 66361 o 66201 Central Station / Terminal S88 Link 9 10 11 12 13 14 15 16 Montaje Retorno de Conexión a Central Station Vía o pulsadores Retorno de masa...
  • Seite 46: Esquema Sinóptico De Conexionado

    Esquema sinóptico de conexionado Puede conservarse una conexión ya existente del S88 en la Central Station 2. Es posible conectar a un Link 88 un máximo de 31 S88 y/o 62 S88AC/S88DC. 8 7 6 5 4 3 2 1 decoder s 88 9 10 11 12 13 14 15 16 Máx.
  • Seite 47: Alimentación Eléctrica

    Alimentación eléctrica: 5 V en el modo mixto de productos de Märklin S88 y S88 AC/DC (como se muestra en la Fig.) así como productos de otros proveedores. 12V solo junto con S88 AC/DC. Si la alimentación eléctrica se realiza a 12 V, se reduce la propensión a fallos y averías. Patillaje del conector RJ45 Color PIN S88 Nombre...
  • Seite 48: Configuración Del L88

    Confi guración del L88 Ahora puede confi gurar los distintos datos. Antes de la puesta en servicio del L88, éste debe confi gurarse. Para ello, en la CS vaya a Setup/Info y con el Para ello, en la CS vaya a Setup/Info y con el icono de herramienta acceda al modo Confi guración.
  • Seite 49 Ejemplo: Contactar 8 • Filas de teclado Modul 2 Introducción de las filas (máx. 8) de la matriz de teclado Bus 2 Direccionamiento de los módulos: Los módulos se direccionan automáticamente al enchufar- los. Para la configuración de las direcciones en la Central Station, éstas se incluyen a continuación.
  • Seite 50 Ejemplos de conexión de los diferentes contactos de señalzación El retorno a masa para todos los contactos de vía se requiere 1 sola vez. Conexión al sistema de vías Märklin H0 con la vía de conmutación Bus 1 Bus 3 Bus 2 = Sentido de marcha que señaliza...
  • Seite 51 Conexión al sistema de vías Märklin H0 con contacto de láminas (reed) Señalización en función del sentido de marcha Bus 1 Bus 3 Bus 2 S 88 Link 9 10 11 12 13 14 15 16 Se requiere el retorno a masa por cada contacto de láminas (reed) Conexión a sistemas de vías de dos conductores independiente- mente del tamaño de ancho de...
  • Seite 52: Uso Como Matriz De Teclas

    Uso como matriz de teclas (pupitre de mando de agujas) Conexionado del pupitre de mando de agujas Es posible conectar un máximo de 8 pupitres de mando de Si desea utilizar el L88 para una matriz de teclas, debe agujas (entradas 9-16) realizar la siguiente configuración.
  • Seite 53 A continuación, introduzca el dispositivo asignado (en este Tabla de direcciones para las teclas caso 17). Tener presente que el diodo debe estar montado en el sentido de bloqueo hacia la salida. Ejemplo Botón 1: 9 salida conectada a la entrada 1 = dirección 101 (Entrada) 1 (Salida) Si ha introducido todo correctamente, confírmelo marcando el...
  • Seite 54: Impiego Commisurato Alla Destinazione

    Avvertenze importanti Impiego commisurato alla destinazione • Le istruzioni di impiego sono un elemento costitutivo del • Il modulo di retroazione L88 è destinato al collegamento prodotto e devono pertanto venire conservate nonché conse- alle Central Station (CS2) 60213/60214/60215 a partire dal gnate in dotazione in caso di ulteriore cessione del prodotto.
  • Seite 55: Collegamento

    60881/60882 60880/6088 Alimentazione di cor- 60881/60882 rente del commutatore S88/S88AC/S88DC Alimentazione di Bus 1 Bus 3 Bus 2 corrente 66361 oppure 66201 Central Station / S88 Link Terminal 9 10 11 12 13 14 15 16 Ritorno di Binario oppure tasto Ritorno di Collegamento massa...
  • Seite 56: Panoramica Delle Connessioni

    Panoramica delle connessioni Un preesistente collegamento dello S88 alla Central Station 2 può venire mantenuto. Ad un solo Link 88 possono venire connessi al massimo 31 S88 e/o 62 S88AC/S88DC. 8 7 6 5 4 3 2 1 decoder s 88 9 10 11 12 13 14 15 16 Max.
  • Seite 57 Alimentazione di corrente: 5V nell’esercizio promiscuo di prodotti Märklin S88 e S88 AC/DC (come rappresentato in fig.), nonché di prodotti di altri fornitori. 12V solo in abbinamento con S88 AC/DC. In caso di un’alimentazione di corrente a 12V viene ridotta la vulnerabilità dai disturbi. Assegnazione dei PIN del connettore RJ45 Colore PIN S88 Nome...
  • Seite 58: Configurazione Dello L88

    Confi gurazione dello L88 adesso i singoli dati possono venire impostati. Prima della messa in servizio dello L88 questo deve venire confi gurato. A tale scopo vogliate andare nella CS su setup/ A tale scopo vogliate andare nella CS su setup/ Info, adesso con il simbolo „Attrezzi“...
  • Seite 59 • Righe della tastiera Esempio : Contatto 8 Impostazione delle righe (max. 8) della matrice di tastiera Modul 2 Bus 2 Indirizzamento dei moduli I moduli si indirizzano automaticamente mediante l’innesto. Per le impostazioni nella Central Station potete trovare gli indirizzi qui di seguito.
  • Seite 60 Esempi per il collegamento dei differenti contatti di notifica Ritorno di massa per tutti i contatti del binario solo 1x necessario. Connessione al sistema di binario Märklin H0 con il binario di commutazione Bus 1 Bus 3 Bus 2 = Notifica dipen- dente dalla direzione di marcia.
  • Seite 61 Connessione al sistema di binario Märklin H0 con contatto Reed Notifica indipendente dalla Bus 1 Bus 3 Bus 2 direzione di marcia. S 88 Link 9 10 11 12 13 14 15 16 Il ritorno di massa è necessario per ogni contatto Reed Connessione a sistemi di binario a due rotaie, indipendentemente dalla dimensione dello scartamen-...
  • Seite 62: Utilizzo Come Matrice Di Tasti

    Utilizzo come matrice di tasti (quadro di comando) Connessione quadro di comando possono venire collegati al max. 8 quadri di comando Se Voi desiderate utilizzare lo L88 per una matrice di tasti, (Ingressi 9 - 16). allora devono venire intraprese le seguenti impostazioni. 72720 / 72729 / 7272 Ingresso Tramite l’impostazione come matrice possono venire sup-...
  • Seite 63 Dopodiché introducete l’apparato coordinato (qui 17). Tabella di indirizzi per i tasti Si prega di fare attenzione, il diodo deve venire installato in direzione di blocco verso l’uscita. Esempio Button 1: 9 uscita collegata all‘ingresso 1 = Indirizzo del 101 (Ingresso) Se tutto è...
  • Seite 64: Användning Av Produkten

    In- och utgångar på Link 88 Användning av produkten Strömförsörjning: Nätenhet 66361 eller 66201. • Återkopplingsmodulen L88 är avsedd att anslutas till Central Station (CS2) 60213/60214/60215 med mjukvaru- Anslutning till Central Station / Terminal Jordåterkoppling version 3.8.xx eller senare. (när den används som återkopplare) •...
  • Seite 65: Anslutning

    Anslutning Anslutning till Central Station Link 88 ansluts direkt till Boosteranslutningen på CS2 eller till Terminal 60125. För strömförsörjningen ansluter man därefter en nätenhet 66361, eller 66201. Bus 1 Bus 3 Bus 2 Central Station / Terminal S88 Link 9 10 11 12 13 14 15 16...
  • Seite 66: Översikt: Anslutninga

    Översikt: Anslutninga En befintlig anslutning av S88 till Central Station 2 kan bibehållas. Till en Link 88 kan man maximalt ansluta 31 st S88 och/eller 62 st S88AC/S88DC 8 7 6 5 4 3 2 1 decoder s 88 9 10 11 12 13 14 15 16 Max.
  • Seite 67 Strömförsörjning: 5V i blandad trafik mellan Märklins produkter S88 och S88 AC/DC (så som visas på bilden), samt med produkter från andra tillverkare. 12V endast i förbindelse med S88 AC/DC. Vid strömförsörjning med 12V blir risken för eventuella strömningar mindre. PIN-beläggningen av kontakterna till RJ45 Färg PIN S88 Namn...
  • Seite 68: Konfiguration Av L88

    Konfi guration av L88 nu kan man ställa in enskilda data. Innan L88 tas i bruk måste den först konfi gureras. För detta går man på CS in på setup/info, nu med verktygssymbolen i konfi gurationsläge. Samtliga följande bilder är exempel: •...
  • Seite 69 • Rader för tangentbord Exempel: Kontakt 8 Inställning av tangentbords-matrisens rader (max 8) Modul 2 Bus 2 Adressering av moduler: Modulerna adresseras automatiskt när konakten ansluts. För inställningar via Central Station används följande adresser. Kontakter (spår): 1-16 Tangentbordsadresser: 101-164 1.2 Användning i spårplans-layout (exempel) Bus 1: 1001 -1496 (t.ex.
  • Seite 70 Exempel på anslutning av olika givares kontakter Jordåterkoppling för samtliga spår-kontakter - endast 1x behövs. Anslutning till Märklins H0-spårsystem med kopp- lingsskena Bus 1 Bus 3 Bus 2 = Av givare angiven körriktning S 88 Link 9 10 11 12 13 14 15 16 Körriktningsberoende kontaktmeddelande...
  • Seite 71 Anslutning till Märklins H0-spårsystem via Reed-kontakt. Oberoende av riktningen kontakt- Bus 1 Bus 3 Bus 2 meddelande S 88 Link 9 10 11 12 13 14 15 16 Jordåterkoppling måste ske via Reed-kontakt Anslutninga till tvåspårs-system, oberoende av spårvidd, endast med Reed-kontakt Bus 1 Bus 3...
  • Seite 72: Användning Som Knapp-Matris

    Användning som knapp-matris (ställpult): Anslutning av ställpult Man kan ansluta max 8 ställpultar (ingång 9 - 16) Vill man använda L88 som en knapp-matris (ställpult), så måste följande inställningar göras. 72720 / 72729 / 7272 Ingång Via inställningar av matrisen kan max 64 knappar användas Inställningarna görs via Memorys konfigurations-läge (se (till 32 magnetartiklar eller 64 körsträckor).
  • Seite 73 Därefter väljs önskad enhet (här nr 17). Adresstabell för knapparna Var god observera att dioder måste byggas in i rätt riktning i förhållande till utgången Exempel Knapp 1: 9 utgång ansluten till ingång 1 = adress 101. (ingång) 1 (utgång) Är allt korrekt inskrivet, bekräftar man detta med den gröna bocken.
  • Seite 74: Hensigtsmæssig Anvendelse

    Hensigtsmæssig anvendelse Ind- og udgange på Link 88 • Tilbagemeldingsmodulet L88 er udviklet til forbindelse Strømforsyning: Forsyningsdel 66361 eller 66201. med Centralstationerne (CS2) 60213/60214/60215 fra Tilslutning til Centralstation / terminal: softwareversion 3.8.xx og højere. Massetilbageførsel (ved anvendelse som tilbagemelder) • Forbindelse med tilbagemeldingsmodulerne 6088/60880/60881 1-16 kontaktforbindelse (Märklin H0 mellemlederskinne og 60882 sker via ovennævnte Centralstation.
  • Seite 75: Tilslutning

    Tilslutning Tislutning til Centralstation Tilslut Link 88 direkte på boostertilslutningen på CS2 eller terminal 60125, og tilslut derefter strømforsyningen 66361 eller 66201. Bus 1 Bus 3 Bus 2 Central Station / Terminal S88 Link 9 10 11 12 13 14 15 16...
  • Seite 76: Tilslutningsoversigt

    Tilslutningsoversigt På Central Station 2 kan der bibeholdes en bestående tilslutning af S88. Der må maksimalt tilsluttes 31 S88 og/eller 62 S88AC/ S88DC til Link 88. 8 7 6 5 4 3 2 1 decoder s 88 9 10 11 12 13 14 15 16 Maks.
  • Seite 77 Strømforsyning: 5V ved blandet drift af Märklinprodukterne S88 og S88 AC/DC (som vist på ill. ) samt med andre producenters produkter. 12V kun i forbindelse med S88 AC/DC. Med en strømforsyning på 12V mindskes risikoen for fejl. PIN-belægning på RJ45-stikket Farve PIN S88 Navn Beskrivelse...
  • Seite 78: Konfiguration Af L88

    Konfi guration af L88 hvorefter de enkelte data kan indstilles. L88 skal konfi gureres inden opstart. Se dertil afsnittet setup/ Se dertil afsnittet setup/ Info i CS, nu vist med værktøjssymbolet i konfi gurations- modus. Alle følgende fi gurer er eksempler: •...
  • Seite 79 • Linjer tastatur eksempel: Kontakt 8 Indtastning af tastaturmatrixens linjer (maks. 8) Modul 2 Bus 2 Adressering af moduler: Modulerne adresseres automatisk efter tilslutning. Til indstil- ling af Centralstation ses adresserne nedenfor. Kontakter (skinne): 1-16 Tasteradresser: 101-164 1.2 Anvendelse i Layout (eksempel); åbn konfigurations- Bus 1: 1001 -1496 (f.
  • Seite 80 Eksempler på forbindelse af forskellige meldekontakter Massetilbageførsel til alle skinnekontakter er kun 1x nødvendig. Forbindelse med MärklinH0-skinnesystemet med spændingsskinnen Bus 1 Bus 3 Bus 2 = meldende kør- selsretning S 88 Link Melding, der er afhængig 9 10 11 12 13 14 15 16 af kørselsretningen.
  • Seite 81 Forbindelse med MärklinH0- skinnesystemet med reedkontakt. Melding, der er uafhængig af kørselsretningen Bus 1 Bus 3 Bus 2 S 88 Link 9 10 11 12 13 14 15 16 Massetilbageførsel er nødvendig pr. reedkontakt Forbindelse med toleder-skinnesy- stemer, uafhængig af sporstør- relse kun med reed kontakt.
  • Seite 82: Anvendelse Som Tastematrix (Kontrolpanel)

    Anvendelse som tastematrix (kontrolpanel) Tilslutningkontrolpanel Hvis L88 skal anvendes som tastematrix, skal følgende Der kan maks. tilsluttes 8 kontrolpaneler (indgang 9 - 16). indstilles. 72720 / 72729 / 7272 Indgang Via indstillingen Matrix kan der maks. understøttes 64 taster (21 magnetartikler eller 64 køreveje). Bemærk, at der til opbygningen pr.
  • Seite 83 Indtast derefter den indordnede enhed (her 17). Adressetabel til tasterne Bemærk, at diodenskalvære indbygget med spærreretningen hen imod udgangen. Eksempel Knap 1: 9 udgang forbundet til indgang 1= adress i 101 (indgang) Når alt er indtastet korrekt, bekræftes dette ved hjælp af 1 (Udgang) det grønne flueben.
  • Seite 84 Due to different legal requirements regarding electro-magnetic compatibility, this item may be used in the USA only after separate certification for FCC com- pliance and an adjustment if necessary. Use in the USA without this certification is not permitted and absolves us of any liability.
