Features
Once the alarm system is activated, three 640x480 pixel images or six 320x240 pixel images are acquired when motion is
detected. The detector can also be used to acquire images manually using a remote control (app, portal or local control
panel).
The detector is initialised for 40 seconds when the control unit enters activation mode or when the detector is set to Test.
The detector does not manage intrusions of movements during the 40 second initialisation period. If the battery of the
detector is flat or if the tamper switch is open, the blue LED lights up during the initialisation period.
When the JP2 is set to Off, the detector will respect a "sleep time" of approximately 1 minute to save energy. If the system
is active, the detector will not repeat the transmission for 1 minute if motion is detected after the transmission. Any motion
detected during this time will reset the sleep time (taking back to 1 minute). Consequently, continuous motion in front of the
detector will not discharge the battery.
Battery and flat battery detection
The detector is powered by two AA 1.5 V lithium batteries.
When the detector battery is flat. When the battery voltage is flat, the detector transmits the flat battery signal to the control
unit. If a flat battery condition is detected, the blue LED lights up for 2 seconds.
While replacing the batteries, after having removed the flat batteries, press the tamper button or the function button twice to
discharge the device completely before inserting the new batteries.
During replacement, pay particular attention not to damage the contacts in the battery holder compartment.
The detector is protected by a tamper switch is compressed when the fixing screw of the cover is tightened. When the fixing
screw of the cover is loosened, the tamper switch is opened and the detector sends a tamper open signal to the control unit
to inform the user. If a motion is detected while the tamper switch is open, the blue LED lights up for 2 seconds.
The detector does not detect the tamper switch state for 5 minutes after the battery is inserted.
If the tamper switch is operated in the 5 minutes during which there is no detection, the detector will immediately transmit
a tamper signal to the control unit.
When the tamper switch is compressed, the resetting of the default settings of the detector (see below) is
deactivated.
The detector regularly transmits a supervision signal to indicate the condition according to the user's setting. The user may
also press the function button once to manually transmit the supervision signal.
The Test mode is used to control the detection coverage of the device not the communication range with the control unit.
To access Test mode, hold the function button pressed for 5 seconds. The blue LED will light up and stay on for
approximately 30 seconds after having released the button. Test mode, which lasts for 3 minutes, will start after this time.
To make a Walk Test, press once the function button.
The detector will start initialisation during the first 30 seconds. The detector does not manage intrusions of movements
during the 30 second initialisation period.
Motion detection in front of the detector can be checked at the end of the initialisation period. The blue LED lights up for 2
seconds after detection.
Setup
Guidelines
- Check that the control unit is working before inserting the batteries in the device.
- Check that the control unit is within the working range while the device is in use.
- A device may be removed from the system only after having removed the battery. This prevents unnecessary battery
consumption.
Connecting to the system
The detector must be learnt by the control unit to transmit the signal if motion is detected. Proceed as follows to perform the
device learning procedure.
1.
(
2.
( )
3.
0 /
4.
"
/
5.
2
-
DS80TC2Q-001C
%
%
%
- .
-
&
-
"
"
&
&
'
/
%
*
&
+
1
-
-
1
-
1
/
- %
&
'
/
#
/
"
7
