Description; Extent Of Delivery - Exsys EX-1185HMVS-WT Anleitung

English

1. Description

The EX-1185HMVS-WT is a plug & play high-speed USB 3.1 (Gen1) metal hub for 4
USB devices. The EX-1185HMVS-WT provides 4 ports for USB devices and 1 uplink
port for PC. It supports all USB connections from 1.1 to 3.1. All ports can fix with screw
lock. Via a external power supply it is possible to provide a maximum of 900mA on each
USB port. The EX-1185HMVS-WT design fully utilize the Genesys chipset, which repre-
sents the latest in SuperSpeed USB interface technology. It uses data transfer rates up
to 5Gbit/s. It provides a secure and very high data transfer on each single port. The EX-
1185HMVS-WT support the Self Powered and Bus Powered mode. The EX-1185HMVS
-WT support a the temperature range of -40°C to 85°C and it is ideal for use in extreme
temperature dependent areas. In addition the EX-1185HMVS-WT is equipped with an
15KV ESD surge protection. The EX-1185HMVS-WT is IP30 compliant. The DIN-Rail
Kit is included in the extent of delivery for installation in a 19" Rack. The DIN-Rail kit will
be tightened with four screwed on the back of the EX-1185HMVS-WT.
Features:
•
Compatible for USB 1.1, 2.0, 3.0 & 3.1
•
Up to 5Gbit/s
•
All Operating Systems are supported
•
All ports are Screw Lock
•
15KV ESD Surge Protection
•
Extended Temperature Range of -40°C to 85°C
•
Certificate for

2. Extent of Delivery

Before you connect the EX-1185HMVS to your PC, you should first check the contents
of the delivery:
•
EX-1185HMVS
•
USB 3.1 (Gen1) Cable (screw lock)
•
DIN-Rail Kit
•
Manual
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
8
EX-1185HMVS-WT
