Description; Extent Of Delivery - Exsys EX-1187HMVS-2 Anleitung

EX-1187HMVS-2

1. Description

The EX-1187HMVS-2 is a USB 3.2 Gen 1 metal HUB for up to seven end devices. The hub is
equipped with 7 ports for end devices and 1 port for connection to PC. It supports all USB ports
from 1.1 to 3.2 and each USB port on the EX-1187HMVS-2 is additionally screwable. Through the
power supply via the Terminal Block or the DC-Connector, 900mA can be provided at each USB
port. The USB 3.2 bus optimally supports the performance of the fast Genesys chipset. The EX-
1187HMVS-2 thus ensures secure data transfer and excellent performance of up to 5Gbps. It sup-
ports only Self-Powered mode and thus it is mandatory to connect an external power supply. In
addition, the EX-1187HMVS-2 is equipped with 15KV ESD surge protection. The EX-1187HMVS-2
supports IP30 standard and comes with a DIN-Rail kit for installation on a DIN-Rail. The DIN-Rail
kit are screwed tight with two screws on the backside.
Features:
•
Compatible for USB 1.1, 2.0, 3.0, 3.1 & 3.2
•
Up to 5Gbit/s
•
All Operating Systems are supported
•
All ports are Screw Lock
•
15KV ESD Surge Protection
•
Certificate for

2. Extent of Delivery

Before you connect the EX-1187HMVS-2 to your PC, you should first check the contents of the
delivery:
•
EX-1187HMVS-2
•
USB 3.2 Gen 1 Cable (screw lock) (EX-K1581V)
•
DIN-Rail Kit (EX-6096)
•
Manual
© Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved
9
English
