Motherboard Layout
10
11
12
13
14
15
16
17
18
2
Downloaded from
www.Manualslib.com
1
24.4cm (9.6 in)
PWR_FAN1
USB 2.0
T: USB2
B: USB3
USB 3.0
T: USB0
B: USB1
USB 2.0
Top:
T: USB4
RJ-45
B: USB5
LAN
PHY
35
34
XFast LAN
33
RoHS
32
AUDIO
CODEC
COM1
HD_AUDIO1
1
1
31
30
1
Power Fan Connector (PWR_FAN1)
2
ATX 12V Power Connector (ATX12V1)
3
1155-Pin CPU Socket
4
CPU Fan Connector (CPU_FAN1)
5
CPU Fan Connector (CPU_FAN2)
6
2 x 240-pin DDR3 DIMM Slots
(DDR3_A1, DDR3_B1, Black)
7
2 x 240-pin DDR3 DIMM Slots
(DDR3_A2, DDR3_B2, Black)
8
ATX Power Connector (ATXPWR1)
9
USB 3.0 Header (USB3_2_3, Black)
Intel Q77 Chipset
Chassis Fan Connector (CHA_FAN2)
SPI Flash Memory (64Mb)
Chassis Fan Connector (CHA_FAN1)
Chassis Speaker Header (SPEAKER1, Black)
SATA2 Connector (SATA2_4, Black)
SATA2 Connector (SATA2_2, Black)
SATA3 Connector (SATA3_0, Gray)
SATA3 Connector (SATA3_1, Gray)
ASRock Q77M vPro Motherboard
manuals search engine
2
3
4
5
CPU_FAN1 CPU_FAN2
ATX12V1
Q77M vPro
PCIE1
XFast RAM
PCI Express 3.0
PCI1
XFast USB
CMOS
PCI2
Battery
ErP/EuP Ready
Front USB 3.0
PCIE2
1
IR1
USB6_7
USB8_9
PANEL1
LPT1
TPM1
PLED PWRBTN
CLRCMOS1
1
1
1
1
1
1
1
HDLED RESET
CIR1
29
28
27
26
25
24
22
23
19
SATA2 Connector (SATA2_3, Black)
20
SATA2 Connector (SATA2_5, Black)
21
Power LED Header (PLED1)
22
System Panel Header (PANEL1, Black)
23
Clear CMOS Jumper (CLRCMOS1)
24
USB 2.0 Header (USB8_9, Black)
25
USB 2.0 Header (USB6_7, Black)
26
Consumer Infrared Module Header
(CIR1, Gray)
27
TPM Header (TPM1)
28
Infrared Module Header (IR1)
29
Print Port Header (LPT1)
30
COM Port Header (COM1)
31
Front Panel Audio Header
(HD_AUDIO1, Black)
32
PCI Express 2.0 x16 Slot (PCIE2, Black)
33
PCI Slot (PCI2, Black)
34
PCI Slot (PCI1, Black)
35
PCI Express 3.0 x16 Slot (PCIE1, Black)
6
7
8
9
10
CHA_FAN2
Intel
11
Q77
12
64Mb
CHA_FAN1
BIOS
13
SPEAKER1
14
1
15
16
PLED1
SATA2_4
SATA2_2
SATA3_0
17
SATA2_5
SATA2_3
SATA3_1
21
20
19
18
