Assembly instruction
3.

Assembling the cabin

ATTENTION!
Note the floor plan on page 8 and the illustrations from page 11 onwards.

3.1. Assembling the base frame

Start with the base frame with the cut-out and then add the left and right base
frames. Screw the corners of the base frames.

3.2. Assembling the cabin walls

Start by mounting the block planks on the rear wall (block planks without holes).
Note the position of the ventilation slider in the 2nd row.
It can be mounted on the left or right.
Proceed row by row.
Screw the corners of the block planks.
Check that the block planks are at right angles before screwing the corners
together (see page 4). Fit the ventilation slider.

3.3. Assembling the glass elements

Start by assembling the corner posts with grooves for glass. Screw them to the
walls. Place the aluminium U-profiles in the groove as shown in the picture and
put in the glass elements. Note that when installing the glass element "glass with
holes drilled for door hinges", you are defining the direction in which the door will
open. The bottom drill hole for the door hinge is 26.3 cm high.
Then mount the solid strip above the glass front. This must be fixed to the corner
post with diagonally drilled screws.
After the cabin is positioned correctly, bond the U-profiles to the floor
using silicone or assembly adhesive.

3.4. Assembling the benches

Mount the bench support slats so that the top is at a height of 82.5 cm.
Screw the side benches to the bench support slat and the bench feet from be-
low. Then screw the bench feet to the side walls.
