Assembly instruction

3.5. Assembling the roof elements

Start at the back with the roof element with the LED light and pay attention to the
cable outlet. After putting in the roof elements, they must be screwed to the walls.

3.6. Mounting the cover slats

Hold the corners of the cover slats on the outside and screw them on from
the inside.

3.7. Installing glass door

Screw the two door fittings onto the glass element, making sure that they are
straight and that the doors open outward.
The door hand les are screwed together from the inside.
The bottom drill hole of the door handle is 92.4 cm high.
The alignment of the fittings is achieved by adjusting / rotating both
plastic inserts.

3.8. Installing the cable cover slats

After installing the electrical devices, the cables can be covered with the cable
cover slat.
p. 10/10
