Issued / Herausgegeben / Publication / Pubblicato
Instruction Leaflet
Bedienungsanleitung
Feuille d'instructions
Foglio d'instruzioni
1
Figures / Figures / Figura
100
80
60
40
20
400
500
A. Relative sensitivity (%)
B. Wave length (nM)
A.
Relative Empfindlichkeit (%)
B.
WellenlŠnge (nM)
A. SensibilitŽ relative (%)
B. Longuer dÕonde (nM)
A. Sensibilit‡ relative (%)
B. Lunghezza dÕona (nM)
ISO-TECH ILM 350 Digital Light Meter
ISO-TECH ILM 350 Digitales Lichtmeßgerät
Loxometro digitale ISO-TECH ILM 350
600
700
800
900
1000
B
11/1999
Luxmètre digital ISO-TECH ILM 350
General
The ISO-TECH digital light meter is designed to give light level
readings up to 50,000 lux. It has a sensor connected to the meter by 1
metre of coiled lead ( when extended ). This allows light measurements
to be made away from the subject area, thereby minimising errors due
to shadow etc.
Recommended Illuminance Values
Corridors, stairs, etc.
Warehouses, storage bays
General office work
Rough bench / machine work
Medium bench / machine work
Drawing offices / shops
Fine bench work
Fine inspection
Minute work
Technical Specifications
Measuring ______________________0-1999 lux - resolution 1 lux
Accuracy ( typical )
(at 23¡C ± 5¡C ) ± 10% of reading + 2 digits
(Accuracy tested by a standard parallel light tungsten lamp 2856K)
Battery life 150-200 hours in continuous use based on
2mA consumption. (9V PP3).
Sampling Time ________________________________0.4 second
Operating Temperature ______________________________0-50¡C
Operating Humidity ______________0-80% R.H.( no condensing )
Dimensions ________________________________L110, W75 D25
Weight ____________________________________________160g
Correction Factors
Mercury Lamp ____________________________________X 1.05
Fluorescent Lamp __________________________________X 1.0
Incandescent Lamp __________________________________X 1.0
Daylight __________________________________________X 1.0
RS Components shall not be liable for any liability or loss of any nature (howsoever
caused and whether or not due to RS ComponentsÕ negligence) which may result
from the use of any information provided in RS technical literature.
V8761
RS Stock No.
203-013
100/150 lux
100/150 lux
300/500 lux
300/500 lux
500/700 lux
750/1000 lux
1000/1500 lux
1500/3000 lux
3000/5000 lux
2000-19999 lux - resolution 10 lux
20000-50000lux - resolution 100 lux
