M O U N T I N G I N S T R U C T I O N S
All rights reserved. Subject to change without notice.
1 About this document
These mounting instructions apply for the RLY3-HAND1 safety relay.
2 Safety information
DANGER
Hazard due to lack of effectiveness of the protective device
In the case of non-compliance, it is possible that the dangerous state of the
machine may not be stopped or not stopped in a timely manner.
Please observe the safety notes provided.
b
For more information about how to work with the protective device, refer to the
machinery documentation or the operating instructions for the protective
device.You can call up the EU declaration of conformity and the current operating
instructions for the protective device by entering the part number in the search
field at www.sick.com (part number: see the type label entry in the "Ident. no."
field).
3 Mounting procedure
Prerequisites
• Mounting is done in accordance with EN 50274 and electrical installation in
accordance with IEC 60204-1 in the control cabinet with enclosure rating
IP54.
• Mounting is done on a 35 mm mounting rail (IEC 60715).
• The mounting rail is connected to the functional earth.
• The safety relay is installed in a vertical orientation (on a horizontal mounting
rail).
• There is at least 50 mm of space for air circulation above and below the
safety relay.
• There is at least 25 mm of space in front of the safety relay (front side). More
space may be needed depending on the connections.
Approach
Attach safety relay to mounting rail.
b
4 Device connection
Prerequisites
• Contact fuse with safety fuse gG or circuit breaker C: 6 A, maximum short-
circuit protection I ≤ 400 A.
• The ground connection of all connected devices must have the same poten‐
tial as A2.
• The connected control devices comply with the required category in accor‐
dance with ISO 13849-1 and SILCL in accordance with IEC 62061 (e.g.
shielded single sheathed cables, separate installation).
• The cables for the control devices must be laid with protection.
Pin assignment of the terminals
Terminal Description
13, 14 1) 2) Enabling current path
23, 24 1) 2) Enabling current path
I1 Safety capable input for control device A, normally open
I2 Safety capable input for control device A, normally closed
I3 Safety capable input for control device B, normally open
I4 Safety capable input for control device B, normally closed
S1 2) 3) External device monitoring input (EDM)
Y1 Application diagnostic output (NC)
A1 Voltage supply 24 V DC
8020873/ZXO8/2018-11-15/de, en, fr
Terminal
e n
A2
The enabling current paths must be supplied by the same voltage supply.
1)
The enabling current path and external device monitoring (EDM) must be wired within the
2)
control cabinet.
• Use with external device monitoring (EDM): Connect N/C contacts of the controlled
3)
actuators between voltage supply U
• Use without external device monitoring (EDM): Connect U
jumper.
5 Status indicator (LED)
NOTE
SICK recommends cutting out the table below and attaching it to the wall of
the control cabinet.
Fault indicators and operational statuses
LED Status
PWR
o
All LEDs
Ö All colors
PWR
O Green
PWR Ö Red
PWR
Ö Red/green
OUT
o
OUT O Green
OUT
Ö Green
S1
O Green
I1 ... I4 Ö Green, alternate
I1 ... I4
Ö Green, simulta‐
neous
Y1
o
Y1
O Green
6 Data sheet
See the operating instructions for a full overview of the technical data.
Operating data
Supply voltage U
V
Switching voltage for enabling current paths 13, 14, 23, 24
At altitudes below 2,000 m above sea
level
At altitudes 2,000 m above sea level ...
4,000 m above sea level
Interfaces
Connection type
Wire cross-section
Single wire (1×)
Fine wire (1×)
Fine wire with ferrule with plastic collar
(2×, same cross-section)
Fine wire with ferrules with or without collar
(1×)
For UL and CSA applications
Description
Voltage supply 0 V DC
and S1.
V
and S1 with a wire
V
Possible cause
No supply voltage
Initialization with LED test
No fault
• Supply voltage too low temporarily or
permanently
• Internal error
Error
Additional LEDs flash for accurate diagnosis.
Enabling current paths open
Enabling current paths closed
Error in enabling current path
N/C contact of actuator closed
Input error: discrepancy time expired (I1/I2 or
I3/I4)
Input error: process error
Enabling current paths closed
Enabling current paths open
ReLy HAND1
24 V DC (16.8 V DC ... 30 V DC)
10 V DC ... 250 V DC
10 V AC ... 250 V AC
10 V DC ... 150 V DC
10 V AC ... 150 V AC
ReLy HAND1
Spring terminal
0.2 mm ... 1.5 mm
2 2
0.2 mm ... 1.5 mm
2 2
≤ 0.5 mm
2
0.25 mm 2 ... 1.0 mm 2
26 AWG ... 14 AWG
(use only copper wire (60/75 °C))
