Model
Power Input
Voltage
-1
No Load min
-1
Rated Load min
Capacity-Wet (Rig-Mounted)
Capacity-Dry
Arbor Thread
Neck Diameter
Dimensions
Net Weight
DM6D Wet Models
1.
9.
1. Spindle 1-1/4"UNC & 1/2"BSP
2. Side Handle Lock Screw
3. Gear Selector
4. Tubular Spirit Level
5. Lock Button
6. Trigger Switch
7. Main Handle
8. Water Feed Valve
9. Side Handle Assy.
10. Bull's Eye Level
11. Indicator Light
12. Water Feed Adaptor Head
13. Vacuum Adaptor Head
GB
DM6D (Wet)
220-240V: 2000W, 110-120V: 1700W
See machine nameplate
930 / 1520 / 427
560 / 910 / 2560
162mm (6 1/4")
n/a
1 1/4"UNC & 1/2" BSP
60mm
528mm x 106mm x 145mm
6.4kg (14 Lbs.)
2.
3.
8.
DMC6D (Wet / Dry)
182mm ( 7-1/4")
4.
11.
DMC6D Wet / Dry Convertible Model
12.
2
11.
5.
10.
13.
8.
7.
6.
