Tab. 1 :
Connections
on the component
Mounting
Ident.
1 Connection
2 Terminating resistor
3 Relay board address
4 Micro USB
connection,
5 KAPI connection
6 Relays 1 to 8
7 Inputs IN1 to IN8
Comment
– Connection to the
KESO Integra Door Controller
S2 – Last relay board in the RS-485 bus
system: Terminating resistor must be
connected.
– for the other relay boards, the termi-
nating resistor must not be connected.
Address 1 to max. 8
USB No function assigned
KAPI No function assigned
COM- – eight addressable outputs
NC-NO – red LED signals relay in active state
(COM-NO)
– relay not activated (COM-NC)
The function of inputs IN1 to IN8 can be
selected accordingly in KESO k-entry
management software:
– No function
– Remote opening
– Permanent locking
®
