1. Description

The EX-1596HMVS is a plug & play high-speed USB 2.0 managed metal hub for 6 USB
devices. The EX-1596HMVS provides 6 ports for USB devices and 1 uplink port for PC.
It supports all USB connections from 1.1 to 3.2. All ports can fix with screw lock. Via a
external power supply it is possible to provide a maximum of 900mA on each USB port.
With the management software, it is possible to control the hub remotely. For example,
you can easily turn the downstream ports on and off individually or collectively, remotely
restart the hub, reset it to factory defaults and assign a password to prevent unauthor-
ized access via the software. The EX-1596HMVS also has a flash memory that allows
you to save your settings. The EX-1596HMVS design fully utilize the Genesys chipset,
which represents the latest in Hi-Speed USB interface technology. It uses data transfer
rates up to 480Mbit/s. It provides a secure and very high data transfer on each single
port. The EX-1596HMVS support only the Self Powered mode. In addition the EX-
1596HMVS is equipped with an 15KV ESD surge protection. The EX-1596HMVS is
IP30 compliant. The DIN-Rail Kit is included in the extent of delivery for installation in a
19" Rack. The DIN-Rail kit will be tightened with two screws on the back of the EX-
1596HMVS.
Features:
•
Compatible for USB 1.1, 2.0, 3.0, 3.1 & 3.2
•
Up to 480Mbit/s
•
All Operating Systems are supported
•
15KV ESD Surge Protection
•
Certificate for

2. Extent of Delivery

Before you connect the EX-1596HMVS to your PC, you should first check the contents
of the delivery:
•
EX-1596HMVS
•
USB 2.0 Cable (screw lock)
•
DIN-Rail Kit (EX-6096)
•
Driver CD
•
Manual
