Topcom TwinTalker 3500
1. DESCRIPTION
(see front cover)
1. Microphone
2. Monitor button
3. Talk button
4. Call button
5. Ear/mic/charger
6. Antenna
2. INSTALLATION
2.1. Removing/Installing the Belt Clip
1. To remove the clip from the unit, push up on the belt clip (2) while pulling the clip tab (1).
2. When re-installing the belt clip, a click indicates the BeltClip is locked into position.
2.2. Battery Installation
1. Remove the belt clip (2).
2. Pull the Battery Cover Tab (4) and remove the Battery Cover (3).
3. Install four 'AAA' alkaline or rechargeable batteries following the polarity as shown.
4. Re-install the Battery Cover (3) and Belt Clip (2).
7. LCD display
8. Up/Down button
9. Menu/Lock button
10.On/Off button
11.Scan button
12.Speaker
1
2
3
4
3
