Milnor 48040F7B Wartung Seite 41

Figure 14: Steam Inlet Strainer. These are examples. Your machine can look different.
42044SP2 Washer-extractor
.
WARNING 27 : Risk of severe injury—You can accidentally release pressurized steam.
• Close the external shutoff valve and release remaining pressure before you do
maintenance.
Figure 15: Compressed Air Inlet Strainers. These are examples. Your machine can look different.
T-Strainer. Outside machine
frame on some models.
caution statement 28
1. See
strainer.
2. Compressed air in.
.
76039CBW Tunnel Washer
T-Strainer. Inside machine
frame on some models.
Legend
. Remove plug to remove
37
Chapter 3. Routine Maintenance
Legend
1. Steam strainer. Remove
steam pressure before
you remove the plug. See
warning statement
27
2. Steam valve
Y-strainer. Used on some
models
PELLERIN MILNOR CORPORATION
