Connecting Video camera and Video recorder

Video camera
Connect the AV cable to the TV and to the video cam-
era.
Turn on both video camera and the TV.
Select AV/CVBS source
You can now see the playback picture from the video
camera. Note:
To connect the video camera using other cables, refer
to the video camera instruction manual.
Video recorder
Connect the Scart cable to the TV and video recorder.
Turn on both video recorder and the TV.
Select Scart source
You can now see the playback picture from the video
recorder.
Note:
To connect the video recorder using other cables, refer to
the video recorder instruction manual.
Use Scart adapter cable
Mini Audio and Video transfer
(Mini AV cables are supplied)
12
Downloaded from www.Manualslib.com
Video recorder
Scart cable
Video camera
cable
manuals search engine
Florenz 55 cm (21,5") LCD-TV

Connecting an audio system

You can supply the TV sound to the stereo system (A) with
the Scart socket. Use a special Scart cable SCART to RCA.
(Please consult y structions for details). If you
have a surr
Scart cable or the special Scart cable Scart to RCA.
Scart to RCA cable
Scart cabl
Coax cable
(All illustrated cables are not supplied)
coder (B) Use the
(A)
e
