Connection and operating types
5.6. Initial operation
For the connected motor which is connected to the commeo Timer
BT, the runtime has to be set.
Note: The extension inputs are only activated when the runtime has
been set. The runtime will be set with the UP/DOWN buttons.
5.6.1. Runtime setting
A one-time moving interruption when moving up and down as well as
an orange flashing status LED signalize the setting of the runtime.
Note: The runtime calculation for the commeo Timer BT must be
executed without voltage interruption. When the voltage will be inter-
rupted during the setting, you must start over with the first step!
Operation
or
3 s
or
3 s
Note: Alternatively the runtime setting can also be done with a
commeo transmitter in the SELECT mode or via the app in the
device administration.
Motor
Move the blind to the lower end posi tion
with the UP or DOWN button.
Press the STOP button of the transmitter for
3 seconds to save the lower end limit positi-
on.
Move to the upper end position.
Press the STOP button of the transmitter
for 3 seconds to save the upper end limit
position. Perform a test run.
