Ports

The digital central station is equipped with ports for a main track, a programming track, a reverse loop
relay and further Loco-Net ®
LN-T
Prog.
Gleis
SmartBox
light
schw. rot
rot grün
programming track
The programming track serves only for the programming of DCC decoders. During operation it carries
no current and must not be connected to the main track.

1. First steps with the PIKO SmartControl

First, connect all components according to the following graphic.
SmartBox
light
schw.
rot grün
Next, turn on the operating voltage by plugging the power supply into the power outlet. A switchable
The green control LED should now be turned on and the PIKO SmartController
loco mode.
devices as well as a port for the power supply.
LN-B
KS- Haupt
Relais Gleis
rot +
schw.
15V-
power
supply
main track
LN-T LN-B
Prog. KS- Haupt
Gleis Relais Gleis
rot +
rot
schw.
15V-
power
supply
19
light
should display the
