EFE400M Handbook
Non-Standard Models:
Non- Standard model: Y60001# (# can be any letter) (EFE400M-48-5-BCSDL-
NT)
Output Channel
Channel 1
Standby output
Additional variations and limitations of use for Non- Standard model Y60001#:
1. Maximum ambient 50°C.
2. * Can be adjusted at the factory only.
Non- Standard model: Y60002# (# can be any letter) (EFE400M-12-5-NNMDL-
NE-V)
Output Channel
Channel 1
Standby output
Additional variations and limitations of use for Non- Standard model Y60002#:
1. Output power de-rated from 450W to 410W from 100V to 90V input. (e.g. channel 1 power 410W at 90V input)
2. IEC/EN60950-1 only.
3. Maximum ambient 40°C.
4. * Can be adjusted at the factory only.
Output Limitations
All outputs are SELV.
Capacitive Loads
These products are designed for use with capacitive loads up to the value shown in the Table below. Applications
where a discharged capacitor is switched onto the power supply output creates additional loading for which a non-
standard product may be required if the peak current exceeds the value shown in the Table below. Consult factory
for details.
Nominal Output Voltage (V)
Max Capacitive Load (uF)
Peak Current for Switched Capacitive Loads (A)
Input Connections:
Molex Sabre 3 pin header: 18A/250V Max.
Molex KK type 3 pin header: 7A/250V Max.
Vout Nom.
Adjustment
Range (V)
48
47 - 50*
5
Fixed
Adjustment
Vout Nom.
Range (V)
12
11.4 - 13.2*
5
Fixed
Output
Maximum
Current (A)
Power (W)
8.33
400
2
10
Output
Maximum
Current (A)
Power (W)
37.5
450 (530**)
2
10
12
33300
45.2
Page 18 of 24
24
48
16600
4150
22.6
9.8
23198 issue 14, Feburary 2015
