EFE400M Handbook
Safety approvals
UL60950-1 and CSA22.2 No.60950-1 - UL Recognised. C-UL for Canada.
IEC / EN60950-1 - CE mark.
IEC/EN60950-1 and IEC/EN60601-1 - CB Report and Certificate.
CE marking when applied to any EFE400M product, indicates compliance with the Low Voltage Directive
(2006/95/EC) in that it complies with EN60950-1, and with Directive 2011/65/EU of the European Parliament and of
the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic
equipment.
UL/CSA 60601-1 - UL + C -UL approval
Fusing: Internal fuses (F1): dual fuses in the L and N line or single fuse in the Live/+ Line, F10AH, 250V, 5x20mm.
Symbols:
AC DC
Caution
Unit Nomenclature
EFE400M or EFE-400M models as described below:
Units may be marked with a Product Code: U6x or Y6x where x may be any number of characters.
Unit Configuration (Description :) Code may be prefixed by NS # followed by / or - (where # may be any number of
characters indicating non- safety related model differences).
Unit Configuration Code:
EFE400Mxy-a-b-cdef-gh-i-j-klm
Where:
x = Nothing or J for Japanese models (may have non-safety differences).
y = Blank for Y2 capacitors from output to earth
P for Y1 capacitors from output to earth
D for Class II (with Y1 capacitors)
a = Channel 1 output Voltage (see Ch1 in the table below, adjustment range column).
b = Standby voltage: see standby voltage in table below.
c = BC for cover and U chassis without fan grill, with fan fitted (temperature controlled). (Y60001x
model only)
HN for Open frame, no fan, with 12V / 1A fan supply.
HU for U chassis (not EFE400MxD models), no fan, with 12V / 1A fan supply.
HC for Cover + chassis (not EFE400MxD models), no fan, with 12V / 1A fan supply.
EC for Cover + chassis (not EFE400MxD models), end fan (temp controlled).
NN for Open frame, no fan, no fan supply.
NU for U chassis (not EFE400MxD models), no fan, no fan supply.
NC for Cover + chassis (not EFE400MxD models), no fan, no fan supply.
HP for perforated cover, no fan, with 12V / 1A fan supply.
NP for perforated cover, no fan, no fan supply.
d = M for Molex KK type 41791 input connector or equivalent.
S for Molex Sabre type 43160 input connector or equivalent.
e = D for AC input with dual fuse.
N – Neutral
EARTH
Warning: Dangerous Voltage
