Axis Thermal Camera Accessories and Spare Parts Installation Guide
This Installation Guide provides instructions for installing and replacing accessories and spare parts
for AXIS Q1921/-E, including
To install the camera on the network, please see the Installation Guide provided with the camera.
For other details about the camera, see the User's Manual, available from www.axis.com

Installation steps

1. Check the package contents against the list below.
2. Hardware overview. See page 6.
3a. Replace the lens. See page 8.
3b. Install the housing. See page 10.
3c. Replace the protective window. See page 13.

Package contents

The package contents vary depending on accessories and spare parts.
Item
Lens
Housing
Front kit
Printed materials
Downloaded from www.Manualslib.com
Axis Thermal Camera
Accessories and Spare Parts
Installation Guide
AXIS T92E23/T92E24 Thermal Camera Housing
Models/variants/notes
10 mm/19 mm/35 mm/60 mm
AXIS T92E23/T92E24 Thermal Camera Housing
Wall bracket
Outdoor network cable 5 m (16 ft.) with gasket
M20 Cable gland (for IP66)
Torx T20 screwdriver
Allen key
Camera screw and washer
Front panel
Frame with premounted protective window and window heater cable
Front panel screw (4x)
Axis Thermal Camera Accessories and Spare Parts Installation Guide (this document)
Drill template
Axis Warranty document
