5. Install the cable cover and tighten the cable cover screws.
6. Connect the camera to the network using a shielded network cable.
7. Loosen the bracket adjustment screw to aim the camera to the point of interest and focus the
camera, see the Installation Guide provided with the camera for information on how to access
the video stream. If the lens has been changed, the camera's image source has to be updated,
see Indoor/outdoor cameras, on page 8.
8. Take the top cover and attach the safety wire to the tab on the bottom cover.
9. Install the top cover. Make sure to tighten diagonally opposite bottom cover screws a few turns
at a time until all are tight. This will help ensure that the bottom cover gasket is compressed
evenly.
10. Loosen the sunshield adjustment screws and adjust the sunshield to the desired position.
