Axis T92E23 Installationsanleitung Seite 9

Axis Thermal Camera Accessories and Spare Parts Installation Guide
Adjust the holder distance
1. Loosen the upper holder screws.
2. Adjust the distance between the upper and lower holder according to the table below.
Lens
Holder
distance
Lens
Holder
distance
Note:
3. Tighten the screws.
Downloaded from www.Manualslib.com
10 mm
35 mm
0-2 mm
0-2 mm
Measure the holder distance on both sides of the camera to make sure the camera and
holders are mounted parallel to each other.
manuals search engine
19 mm
9 mm
9 mm
60 mm
Page 9
10 mm
10 mm
17 mm
17 mm
