I/O Panel
No. Description
1
2
3
4
5
6
7
* here are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
ACT/LINK LED
LAN Port
Activity / Link LED
Status
Of
Blinking
On
Downloaded from www.Manualslib.com
1
13 12
USB 2.0 Ports (USB12)
LAN RJ-45 Port (Realtek RTL8111H)*
LAN RJ-45 Port (Intel® I219V)*
Line In (Light Blue)**
Front Speaker (Lime)**
Microphone (Pink)**
USB 3.0 Ports (USB3_56)
SPEED LED
Description
No Link
Data Activity
Link
manuals search engine
2 3
10 9 8
11
No. Description
8 USB 3.0 Ports (USB3_34)
9 USB 3.0 Ports (USB3_12)
10 DisplayPort 1.2
11 HDMI Port
12 DVI-D Port
13 PS/2 Mouse/Keyboard Port
Speed LED
Status Description
Of 10Mbps connection
Orange 100Mbps connection
Green 1Gbps connection
Z170M-ITX/ac
4
5
7 6
3
