26
Downloaded from
www.Manualslib.com
Chassis Speaker Header
(4-pin SPEAKER1)
(see p.1, No. 11)
Chassis Fan Connector
(4-pin CHA_FAN1)
(see p.1, No. 1)
CPU Fan Connector
(4-pin CPU_FAN1)
(see p.1, No. 2)
FAN_SPEED_CONTROL
ATX Power Connector
(20-pin ATXPWR1)
(see p.1, No. 5)
ATX 12V Power
Connector
(4-pin ATX12V1)
(see p.1, No. 17)
manuals search engine
Please connect the chassis
SPEAKER
speaker to this header.
DUMMY
DUMMY
+5V
1
Please connect fan cables
to the fan connectors and
match the black wire to
FAN_SPEED_CONTROL
CHA_FAN_SPEED
the ground pin.
FAN_VOLTAGE
GND
his motherboard pro-
4
3
2
1
vides a 4-Pin CPU fan
(Quiet Fan) connector.
GND
FAN_VOLTAGE
CPU_FAN_SPEED
If you plan to connect a
3-Pin CPU fan, please
connect it to Pin 1-3.
his motherboard pro-
10
20
vides a 20-pin ATX power
connector. To use a 24-pin
ATX power supply, please
plug it along Pin 1 and Pin
11.
1
11
Using a 24-pin ATX power supply:
Please connect an ATX
12V power supply to this
connector.
