G83/2:2012 [Id 500] Renewed Standard - TELE RE NA003-M64 Benutzerhandbuch

3.5.35

G83/2:2012 [ID 500] renewed standard

Nominal Voltage
ID
.005 ULN/LL nom
Overvoltage1 Line to Neutral
ID
.019 O/V st 1
.021 T O/V st 1
Undervoltage1 Line to Neutral
ID
.023 U/V st 1
.025 T U/V st 1
Overvoltage2 Line to Neutral
ID
.035 O/V st 2
.037 T O/V st 2
Undervoltage2 Line to Neutral
ID
.039 U/V st 2
.041 T U/V st 2
Overfrequency1
ID
.055 O/F st 1 f
THR
f
THR
.057 T O/F st 1 Time OFF
Underfrequency1
ID
.059 U/F st 1 f
THR
f
THR
.061 T U/F st 1 Time OFF
Overfrequency2
ID
.063 O/F st 2 f
THR
f
THR
.065 T O/F st 2 Time OFF
Underfrequency2
ID
.067 U/F st 2 f
THR
f
THR
.069 T U/F st 2 Time OFF
Default
Unom Y V 230.0
Unom Δ V 400.0
U OFF %Unom
THR
U ON %Unom
THR
Time OFF ms
U OFF %Unom
THR
U ON %Unom
THR
Time OFF ms
U OFF %Unom
THR
U ON %Unom
THR
Time OFF ms
U OFF %Unom
THR
U ON %Unom
THR
Time OFF ms
OFF Hz
ON Hz
ms
OFF Hz
ON Hz
ms
OFF Hz
ON Hz
ms
OFF Hz
ON Hz
ms
Seite 87 von 106
Conformity Range
Min
230.0
400.0
Conformity Range
Default Min
114 114
Fixed Hysteresis (0.75% U
1000 1000
Conformity Range
Default Min
87 87
Fixed Hysteresis (0.75% U
2500 2500
Conformity Range
Default Min
119 119
Fixed Hysteresis (0.75% U
500 500
Conformity Range
Default Min
80 80
Fixed Hysteresis (0.75% U
500 500
Conformity Range
Default Min
51.50 51.50
Fixed Hysteresis (0.05 Hz)
90000 90000
Conformity Range
Default Min
47.50 47.50
Fixed Hysteresis (0.05 Hz)
20000 20000
Conformity Range
Default Min
52.00 52.00
Fixed Hysteresis (0.05 Hz)
500 500
Conformity Range
Default Min
47.00 47.00
Fixed Hysteresis (0.05 Hz)
500 500
Possible Range
Max Min
240.0 100.0
417.4 173.9
Possible Range
Max Min
114 100
)
NOM
1000 50
Possible Range
Max Min
87 0
)
NOM
2500 50
Possible Range
Max Min
119 100
)
NOM
500 50
Possible Range
Max Min
80 0
)
NOM
500 50
Possible Range
Max Min
51.50 50.00
90000 1000
Possible Range
Max Min
47.50 40.00
20000 1000
Possible Range
Max Min
52.00 50.00
500 50
Possible Range
Max Min
47.00 40.00
500 50
SW: 01.10.01a / 2020-07-06
Max
240.0
417.4
Max
135
10000
Max
100
10000
Max
135
10000
Max
100
10000
Max
55.00
120000
Max
50.00
120000
Max
55.00
10000
Max
50.00
10000
