EUROLITE IR-20 remote control

The device must be activated for remote control. For this, set the device under menu item IR to ON and
press the ENTER button to confirm activation.
Please dispose of old and used batteries properly. Batteries are hazardous waste and should
Control via IR remote
The Controller has several buttons with following functions:
ON
AUTO
Color change
„Switching";
via ▲▼ the speed
can be regulated
COLOR
Color presets;
via ▲▼ the 16 preset
colors can be chosen
R
ED
W
HITE
O
RANGE
The device features a memory function. The last setting selected will begin anew when the device is
restarted.
Downloaded from www.Manualslib.com
1
direction of the sensor in the middle of the front of the device. There must be
visual connection between the remote control and the sensor.
2
foil between the battery and the battery contacts prevents the battery from
being discharged during storage. Prior to the first operation remove the foil
from the battery support on the rear side
remote control. Otherwise operation of
control is not possible.
3
replace the battery. For this purpose, on the rear side of the remote control
press the small bar with the groove to the right and at the same time remove
the battery support. For operation, one 3 V button cell type CR2032 is
required. When inserting, pay attention that the positive pole of the button cell
shows upwards in the support.
Danger of explosion when battery is replaced improperly. Only replace by the same type.
not be disposed of with regular domestic waste!
OFF
FADE
Color change
„Fading";
via ▲▼ the speed can
be regulated
MASTER
Master setting
G
REEN
A
MBER
C
YAN
manuals search engine
When actuating a button, always hold the remote control in the
The remote control is supplied with a battery inserted. An insulating
If the range of the remote control
CAUTION!
▲
/ +
Switch through,
Upwards, increasing
STROBE
Strobe effect of the
color set under MANU;
via ▲▼ the speed can
be regulated
SLAVE
Slave setting
B
LUE
UV
P
INK
25/32
of the
the remote
decreases,
▼
/ - Switch
through, downwards,
decreasing
SOUND
Color change
„Sound controlled"
FULL
All colors on
SHUT
Blackout –
LEDs off / LEDs on
DMX starting
ADDRess;
via ▲▼ the DMX
address can be set
Setting DMX
CHannel mode; via
▲▼ the DMX channel
mode can be set
