The working cycle is terminated when either the crimping force is
reached or the cable/conductor, DIN rail, threaded rod is cut.
Afterwards a second working cycle can be initiated or the it can be
finished by opening the latch (Pos.-No. 3 & Picture 2 Pos. A). After the
working cycle is finished the trigger lock (Pos.-No. 8) must be locked
again.
5.1.1 Use of crimping dies
When using the 22 style dies (see picture 2) the retaining clips (Pos.-#
4) have to be actuated (Picture 2 Pos. E) while the dies will be inserted
consequtively from the side into the head respectively the adapter.
The 18 style dies are inserted axially into the universal head,
respectively the adapter. The spring must be placed on the opposite
side of the latch.
During the crimping process the connecting material is positioned in
the stationary half of the die whereas the moving part of the die is
approaching the compression point
After having reached the maximum crimping force the dies return into
the starting position automatically.
5.1.2 Use of cutting dies
Three diffent types of cutting dies are available. The UC 26 is
optimised on copper and aluminium cables/conductors ≤ 26 mm ∅.
The UC 40 can cut all copper and aluminium cables/conductors < 40
mm ∅. The larger cables/conductors show the best results respectively
the least deformations.
For cutting ACSR conductors you must only use the UCACSR cutting
blades.
Fractions of reenforced steel conductors can be propelled towards the
operator with high speed and could cause severe injuries.
When cutting threaded rods they must be in a right angle to the cutting
blades to provide a clean cut. The threaded rods must be cleaned of
chips prior to cutting. The cutting cycle should be proceeded until the
blades have reached their final position in order to provide clean
cutting edges.
The DIN rail cutting dies are equipped with a sheet metal guide which
facilitate a cut in a right angle.
When the cut is completed the retraction is provided by actuating the
retract button (Pos.-No. 2) once.
3
See picture 4 page 2
Downloaded from www.Manualslib.com
Attention
After having terminated the crimping process and
prior to changing the dies pull plug out of socket.
Attention
Do not use the power cord for unintended purposes.
Don't carry the tool by the power cord and don´t use the
cord to pull the plug out of the power receptacle.
Attention
When working outdoors, use only approved extension
cables.
3
.
Attention
Do only cut copper and aluminium cables/conductors
with UC 26 and UC 40!
Attention
Cutting ACSR conductors or steel fortified
cables do always wear safety glasses.
