Installation

Surface Mounting

1C Attach the included mounting
brackets to the sides of the PDU
with the included screws. Note: If
you need to change the
orientation of the PDU to match
the mounting surface, rotate the
mounting brackets in 90°
increments as required before
attaching.
2C Mount the PDU to a stable surface
by inserting four user-supplied
screws through the bracket ears
and into appropriate mounting
holes. Make sure the mounting
surface and screws are capable of
supporting the combined weight of
the PDU and any attached
equipment cords.
3C Attach Cord Retention Brackets
(Optional): Attach the cord
retention brackets to the PDU with
the included screws.
