Installation
Wall Mounting (not applicable to series AG-0151 for PDUMH32HVAT &
PDUMH32HVATNET)
1B Attach one of the supplied
mounting brackets to the wall with
user supplied screws. Make sure
screws and any other hardware
are appropriate for the surface
type.
2B Attach a mounting bracket to the
PDU with the included screws.
3B Place the PDU on the wall-
mounted bracket and secure the
PDU to the bracket and wall as
shown.
18-11-326-93323D.indb 4
continued
1B
2B
3B
3B
4
