I/O Panel
No. Description
1
2
3
4
5
* There are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications.
ACT/LINK LED
LAN Port
Activity / Link LED
Status
Off
Blinking
On
Downloaded from www.Manualslib.com
1
10 9 8
PS/2 Mouse/Keyboard Port
LAN RJ-45 Port*
Line In (Light Blue)**
Front Speaker (Lime)**
Microphone (Pink)**
SPEED LED
Description
No Link
Data Activity
Link
manuals search engine
2
7 6
No. Description
6 USB 3.0 Ports (USB3_5_6)
7 USB 3.0 Ports (USB3_3_4)
8 DVI-D Port
9 HDMI Port
10 USB 3.0 Ports (USB3_1_2)
Speed LED
Status Description
Off 10Mbps connection
Orange 100Mbps connection
Green 1Gbps connection
Z170 Pro4S
3
4
5
