Operating components

(For illustrations see fold-out pages)
GB
Figure A:
Figure B:
Figure C:
Figure D:
8
Light sensor for controlling exposure
Camera head
Loudspeaker
Camera head mounting
Connection panel
Camera base
Microphone
Red operating LED
Focus ring for manual focusing
Camera lens
Infrared LEDs
Yellow control LED for the network connection
Threaded connection for the Wi-Fi antenna
Contact for power supply from the mains adapter
Alarm connection (IN/OUT)
LAN connection
AUDIO output
Thread for attaching the mounting arm
Reset switch
QR code for quick synchronisation with smartphone
Mains adapter
Wi-Fi antenna
Mounting arm
Network cable
Data CD
Plug adapter for alarm connection
Mounting material
Operating instructions
IUK 5 A1
